Hampool 60pcs Marine wiring harness heat resistant Waterproof Heat Shrink Duraseal electrical heat shrink butt connector kit
-
Supplier: Shanghai Hampool Enterprise Co., Limited -
Region: Shanghai, China -
Contact: Ms Sophia Pu -
Price: $0.02 / >=100 pieces -
Min. Order: 100 pieces
| Model Number: | HP-DS; | Volume resistivity: | Min.1014Ω.m; |
| Others: | AWG or brand can printed on outer tube; | Single gross weight: | 0.5 KG; |
| Tensile strength(Room temp.): | Min.10.4Mpa; | Tueb Material: | HDPE; |
| Selling Units: | Single item; | Cable Size: | 22-18/16-14/12-10AWG; |
| Delivery Detail: | 0 days after payment; | Dielectric strength: | >15.8kv/mm; |
| Place of Origin: | Shanghai China (Mainland); | Metal component material: | Copper or brass; |
| Type: | Crimp Terminal; | Color: | Red Blue Yellow; |
| Single package size: | 23X18X6 cm; | Certificate: | ISO9001, SGS, UL,ROHS; |
| Brand Name: | Hampool; | Application: | Wire Connecting, insulation, waterproof; |
| Package Type: | Products packaged by plastic transparent compartmental box.; | Package Preview: | https://sc02.alicdn.com/kf/HTB1.eWVOsfpK1RjSZFOq6y6nFXaq.jpg_640x640.jpg; |
| Property | Specification Requirement | Test Method | Typical Value |
| Tensile strength(Room temp.) | Min.10.4Mpa | UL224 | 17.2Mpa |
| Elongation at break(Room temp.) | Min.200% | UL224 | 280% |
| Tensile strength after aging(158℃ 168hrs) | Min.7.3Mpa | UL224 | 11.5Mpa |
| Elongation after aging(158℃ 168hrs) | Min.100% | UL224 | 200% |
| Voltage withstand(Uh-aged) | Withstand 2.5kv for 1 minute and breakdown | UL224 | pass |
| Voltage withstand(Aged) | Withstand at least half of un-aged breakdown voltage for 1 minute and breakdown | UL224 | pass |
| Copper corrosion(158℃ 168hrs) | No corrosion of bare copper | UL224 | No sign of deg. |
| Copper stabiity(158℃ 168hrs) | No sign of degradation (min.elongation 100%) | UL224 | pass |
| Cold blend(-30℃ 1hrs) | No crack | UL224 | pass |
| Maximum secant modulus(2%) | 173Mpa | UL224 | pass |
| Volume resistivity | Min.1014Ω.m | UL224 | pass |
| Heat shock(250℃ 4hrs) | No crack | ASTM D2671 | pass |
| Dielectric strength | >15.8kv/mm | ASTM D2671 | >25kv/mm |
Hampool Enterprise is a professional company to supply wire and cable systematic protect solutions. We cooperated with German company, America company on technology and products. We have more than 10 years experience in this industry. With strong technology strength, Hampool develop many series high quality products and get good reputation in European market and North American Market. After so many years development, Hampool has been a well known brand in many countries, and meanwhile Hampool become the pioneer brand to shift from “Made in China” to “Created in China".
1.Q: Which certifications or test reports do you have?
A: We have UL and RoHS tested by SGS.
2.Q : How to ship my order ? Is it safe?
"A: For small package, we will send it by Express, such as DHL,FedEx,,UPS,TNT,EMS.
For big packages, we will send them by Air or By sea.We will use good packing and ensure the safety.We will be responsible to any product damage caused on delivery."
3.Q : What about your delivery time?
"A: We have a lot of products in stock.We can send the stock products in 3 work days.
If without stock,or stock is not enough, we will check the delivery time with you."
4.Q: Can you provide samples ? Are the samples free ?
"A: Yes,we can provide samples.
Usually for our standard products with stock, we can supply samples free for testing.
5.Q:Could I put my own logo on it?
A:Sure,of course,we are a professional manufacturer and have over 10 years OEM experience.
-
