YT Torch TC1700 U type Mosi2 flexible ceramic mosi2 heating element for Electric Furnace

Supplier: Yantai Torch Special High Temperature Ceramics Co., Ltd.
Region: Shandong, China
Contact: Ms Eva Wei
Price: $26.00 /piece
Min. Order: 1 piece

Click here to contact

Product details

Certification:	ISO9001;	Port:	Qingdao/Yantai;
Power Source:	Electric;	Brand Name:	YT Torch;
Core Components:	MOSI2;	Condition:	New;
Package Preview:	;	Warranty of core components:	Not Available;
Payment Terms:	L/C,T/T;	Packaging Detail:	Woolden box;
Applicable Industries:	Machinery;	Local Service Location:	Japan,South Korea,None;
Key Selling Points:	High-accuracy;	Warranty:	Depend on using condition,Unavailable;
Dimension:	Customized;	Dimension(LWH):	Customized;
Marketing Type:	Hot Product 2019;	Main application:	Industrial Furnace;
Video outgoing-inspection:	Provided;	Type:	Air Heater;
Machinery Test Report:	Provided;	Material:	Mosi2,mosi2;
Voltage:	Customized;	Product name:	TC1700 MoSi2 Heating element;
Place of Origin:	Shandong China;	Supply Ability:	20 Ton/Tons per Month;
Showroom Location:	None;	Weight:	Customized;
After Warranty Service:	Video technical support,Online support;

YT Torch TC1700 U type Mosi2 heating element Electric Furnace

Product Description

Product Name	TC 1700 MoSi2 Heater
Condition	New	Color	Gray
Place of Origin	Yantai,China(Mainland)	Max. Element Temperature	1700℃
Dimension(LWH)	Customized	Power Source	Electric
Power(W)	All Depends	Model Number	TC1700 Type
Volume Density	5.8±0.1g/CM3	Voltage	All Depends
Type	Air Heater	Shape:	U,W,L and customized
Band Name	YT Torch	Weight	All Depends

Application

Physical Properties	Density-g/cm3	Bending strength under room temperature-MPa	Hardness-GPa	Compression Strength-Mpa	Water absorption-%	Thermal elongation-%
Physical Properties	5.8±0.1	450	11	>1500	≤0.2%	4
Maximum Temperature-℃	Air	N2 Nitrogen	He Ar Ne Argon,Helium	H2-80℃ Dry Hydrogen(dew point)	Mixed gas (e.g.10% CO2 and 50% CO and 15%H2)	Cracked and partiallly burnt ammonia(8% H2)
Maximum Temperature-℃	1700	1600	1600	1150	1600	1400
Application	Electric furnaces under non-oxidizing atmosphere

How to Assembly

Packing&Delivery

Related Products

Produce Process

YT Torch TC1700 U type Mosi2 heating element Electric Furnace

About Us

{ Learn More+ }

1.Product has the capabilities to resistance to oxidation and automatically repair, suitable for continued using in any kinds of oxidizing atmospheres.

2.Product is shaped in hot-working process, which keeps the base material in good tenacity and plasticity at high temperature. The geometrical figure, standard and dimension is canonical, may produce any special shape and any dimension to meet the customer requirement.

3.Because of the special technology, welding spot is firm and shock resistance, which dramatically reduced the damaged probability of welding spot by electric current, as well as transit and installation.

4.High density of YT Torch product increases its electrical conductivity. The characters of faster warming and power consumption low, which reduce production cost.

5.Good appearance quality and tenacity, high mechanical strength.

6.Protective layer of quartz glass is compact and good adhesion with the substrate

7.Excellent high temperature strength which is not easy to deform in use
