Complete line of Big Bag Production Line Jumbo/Container/FIBC Bags/tarpaulins Eight Shuttle Circular Loom

Product details
Machinery Test Report:Provided;Local Service Location:None;
Condition:New;Weight:10;
Brand Name:TIANFENG;Warranty:1 Year;
After-sales Service Provided:Video technical support,Field installation, commissioning and training,Field maintenance and repair service;Dimension(L*W*H):10x10x10;
Voltage:380V, 50Hz;Core Components:PLC,Engine,Bearing,Gearbox,Motor,Pressure vessel,Gear,Pump;
Woven bag machine:Jumbo bag;Power(W):100kw;
Warranty of core components:1 Year;Processing Type:Other;
Key Selling Points:Easy to Operate;Packaging Detail:naked or wooden case;
Port:Ningbo Port, China;Applicable Industries:FIBC Woven bag machine;
Payment Terms:L/C,T/T;Showroom Location:None;
After Warranty Service:Video technical support,Online support,Spare parts,Field maintenance and repair service;Supply Ability:200 Set/Sets per Month;
Video outgoing-inspection:Provided;Certification:ISO and CE;
Marketing Type:New Product 2020;Place of Origin:Zhejiang China;

Complete line of Big Bag Production Line Jumbo/Container/FIBC Bags/tarpaulins Eight Shuttle Circular Loom

Jumbo/Container/FIBC Bags Eight Shuttle Circular Loom

This machine is used to weave endless tubular or flat heavy or light fabric of PP or HDPE for jumbo bags, container bags, geotextiles, tarpaulins, etc.

--------------------------------------------------------------------------------------------------------------------------------------------------------------

Zhejiang Tianfeng Plastic Machinery Plant as the pioneer manufacturer deals with  PP woven bag machinery field more than 20 years. We are profession Manufactures PP Flat Yarn Making Machine,Monofilament Yarn Extruder Machine,4/6/8 Shuttles Circular Loom,Multifunctional Leno Circular Loom,Plastic Laminating Machine,Automatic Bag Cutting and Sewing Machine,Flex/Greavure 6 Colors Printing Machine,High Speed Film Blowing Machine,Computer Film Bag Heating Cutting and Sealing Machine and so on
---PP/PE Tubular Woven Bags Product Line
---PP/PE Tubular Laminated Bags (Cement Bags) Product Line
---PP/PE Colored and Laminated Woven Bags Product Line

---PP/PE Flour Woven Bags Product Line

---PP/PE cement Woven Bags Product Line

---PP/PE sugar Woven Bags Product Line

---PP/PE rice Woven Bags Product Line

---PP/PE fertilizer Woven Bags Product Line

---PP/PE wheat Woven Bags Product Line

---PP/PE Food Woven Bags Product Line

---PP/PE chemic powder Woven Bags Product Line
---PP/PE Laminated Bags With Mid-Seam (Cement Bags) Product Line
---PP/PE Jumbo/Container/FIBC Bags Product Line
---PP/PE Tarpaulin / Flat Woven Fabric Sheet Product Line
---PP/PE Leno Mesh Bag Production Line
---HD/LD/LLD PE Shopping/T-shirt/Rubbish/Garbage  Bags Product Line
---PP/PE Rope Making Machines Line

---PP/PE Sun-Shade Net Production Line

Main Technical Parameters

Model

S-YZJ-8/2200

Number of shuttles

8 pcs

Rotational speed

30-70 r.p.m.

Weft density

20-55wefts/100mm

Max. number of warp

2400pcs (1200 pcs×2)

Working width, double-flat

1800-2200mm

Inner dia. of core

Ø38mm

Length of core

230mm

Max. dia. of warp bobbin

Ø120mm

Max. dia. of weft bobbin

Ø110mm

Length of warp/weft bobbin

200mm

Driving main motor and control

Warp infeed motor and control

7.5kw, inverter control

2sets, torque control

Fabric haul-off and control

By mechanical drive, 1 set

Winder motor and control

torque control

Length of winding core

2300mm

Max. dia. of winding roll

Ø1200mm

Over dimensions (L×W×H)

13150×3500×4500mm

Composition of the Standard Loom



Frame

1set

Creels stand

2unit

Central drive system (small cam, A.C. motor)

1unit

Positive warp infeed system with torque motor

2unit

Warp break detecting system

1unit

Weft break detecting system

1unit

Weft pre exhaust detecting system

1unit

Shuttle assembly

8units

Shuttle motion guide

1unit

Weaving size ring

1unit

Bobbin storage above the intake

2units

Manual operation control unit

3units

Fabric haul-off system

1unit

Electronical meter counter

1unit

Standard width surface winder

1unit

Loom control system

1unit

Main Electric Elements List



Loom controller

Wenzhou, China

Warp monitoring sensor

China or India

Central main motor

Wannan Motor, China

Motor for warp feeding

Changzhou or Wenzhou, China

Motor for fabric winding

Changzhou or Wenzhou, China

Inverter

China

Breaker

DELIXI, China

Other low-voltage electric

DELIXI, China

Wire terminal

Wenzhou, China

 Sample Jumbo bag from machines
