Power saving 16000kN EPC CNC electric screw press machine

Product details
Type:Pressing machine;Place of Origin:Guangdong China;
Warranty:1 Year;Brand Name:Sun Glory;
After-sales Service Provided:Field maintenance and repair service;Applicable Industries:Cookware;
Condition:New;Product name:CNC power driven screw press;
Packaging Detail:Wrapped by film or packed with fumigated wooden case. cookware inner polishing machine;Payment Terms:L/C,D/A,D/P,T/T,Western Union,MoneyGram,Deposit by cash;
Feature3:Electrical control system uses PLC;Feature2:High starting torque;
Supply Ability:10 Set/Sets per Month Inner polishing machine;Feature1:Save approx 50% electricity.;
Automatic Grade:Automatic;Port:FOB Shenzhen;

Power saving 16000kN EPC CNC electric screw press machine

Product Description

 Advantages:

1. Form the forming process, adjust the striking force and combat powers base on the forging.

2. Using Switched Reluctance Drive, it has a low starting current, high starting torque, and good speed performance.

3.Save approx 50% electricity.

4.Electrical control system uses the programmable logic controller(PLC) as the master device, to realize the real-time control of the machine and man-machine interface(HMI) enables information exchange between the speed operator and the machine.



Model

Nominal pressure

(KN)

Allow the use of force

(KN)

Slide stroke

(mm)

Strokes per minute

(min-1)

Min.space for installing

(mm)

Thickness of table plate

(mm)

Table size F.B×L.R

(mm)

EPC54-10001000016000500186001801000×900
EPC54-16001600025000550167502001200×1100
EPC54-250025000400006501410202801400×1250
