400m crawler core water well drilling rig machine for sale

Supplier: Goldenman Petroleum Equipment Co., Limited
Region: Shandong, China
Contact: Mr Shine Lee
Price: $47000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Product name:	400m crawler mounted core water well drilling rig machine for sale;	Mobility:	crawler mounted;
Packaging Detail:	Bundle or Oil-coated or Bituminous, pipe ends with beveleds, threads and caps according to your requirement;	Single package size:	530X200X270 cm;
Type:	Other;	Usage:	underground pipe and cable laying;
Single gross weight:	9000.0 KG;	Brand Name:	GM;
Local Service Location:	None;	Certification:	ISO9001;
Applicable Industries:	Construction works ;	Application:	core ,water;
Warranty:	1 year;	Condition:	New;
Power Type:	Diesel;	Core Components:	Pressure vessel,Engine;
Marketing Type:	New Product 2020;	Selling Units:	Single item;
Machinery Test Report:	Provided;	Weight:	5800kg;
Warranty of core components:	1 Year;	Drilling Depth:	150-400m;
Key Selling Points:	Sustainable;	Place of Origin:	Shandong China;
Dimension(LWH):	410018002400 mm;	Showroom Location:	None;
Video outgoing-inspection:	Provided;	Drilling Diameter:	300mm;

450m crawler core water well drilling rig machine for sale

Product Description

450m crawler core water well drilling rig machine for sale

main feature of 450m crawler core water well drilling rig machine for sale
1. The pneumatic water well drilling rig is mechanical transmission, the other is hydraulic transmission, and the power is effectively utilized. The overall power loss is small and the drilling cost is low.
2. The water well drilling rig has more positive speed series and 14-500r/min speed range, and the output torque is 13428-250N.m.
3, the rig has a 2 speed reverse speed, easy to deal with accidents.
4. The water well drilling rig adopts long-stroke double-speed mechanism and mechanical power head, and the power head stroke is 3800MM, which is used to improve drilling efficiency and reduce the occurrence of blockage and burning drill accidents.
5. The water well drilling rig adopts double oil pump for oil supply. When drilling, it uses single pump. When lifting the drill,it uses two pumps to merge; the power loss is small and the auxiliary time is short.
6. The rig has advanced structure and reasonable layout, which is convenient for maintenance, maintenance and repair.
7, using the crawler chassis, the leg cylinder stroke 1.5m can be automatically loaded, easy to move and transport.
8. The water well drilling rig is in machinery. Some functional interfaces are reserved in the hydraulic system, and the functions
can be expanded according to the process requirements of different users.

Our Services

Technical Parameter

The technical parameters of GMZ450L drilling rig
Model			GMZ450L
Total Weight(T )			8.7
Dimensions(mm )			530020502700
Drilling Diameter(mm)			130-400
Drilling Depth(m)			450
One-time Advance Length of the Drill(mm)			3000/6000
Walking Speed(km/h)			6
Climbing Ability(max )			25
Min.Ground Clearance(mm )			300
Working Air Pressure(Mpa )			1.7-3.5
Air Consumption(m3 /min )			17-35
Main Power(kw)			100/6 cylinder
Rotation speed(rpm)			45-75
Rotary Torque(N.m )			9000-10000
