2019 New Designed Small Portable Concrete Pumping Machine For Sale

Supplier: Qinhuangdao Lulong HT Engineering Machinery Factory
Region: Hebei, China
Contact: Mr. Andy Xin
Price: $4500.00 /set
Min. Order: 1 set

Click here to contact

Product details

Radiator:	Air Cooling;	Conveyer Pipe Diameter:	75mm;
Dimension(LWH):	1700x650x110mm;	Warranty:	12 Months;
Port:	Tianjin,Qingdao;	Supply Ability:	500 Set/Sets per Month Wall Plastering Machine;
Packaging Detail:	Stanard Export Wooden Case Concrete Pumping Machine Small Concrete Pump Portable Concrete Pump;	Place of Origin:	Henan China (Mainland);
Vertical Pumping Distance:	15m;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;
Weight:	360kg;	Power:	3.75Kw;
Pumping Capacity:	7.1 M3/Hour;	After-sales Service Provided:	Video technical support,Online support;
Condition:	New;	Electricity (Voltage/Hz):	Customized;
After-sales Service Provided:	Engineers available to service machinery overseas;	Certification:	ISO;
Power Type:	Electric;	Brand Name:	HT;
Horizontal Pumping Distance:	25m;	Max Aggregate Diameter:	25mm;

Concrete Pumping Machine, Portable Concrete Pump, Small Concrete Pump :

Product Description

1 Features :

1.1 This machine adopts mature hydraulic propulsion technology, pump truck principle and revolutionarily uses inclined lifting layout template components,completely solves the shortcomings of the previous secondary structured column pump, such as bulky volume, fast worn, easy pipe plugged and difficult maintenance,it also has powerful effect and excellent performance, it has won the favor of customers after launched to market,.

1.2 The machine has small size (1700x650x110mm) and light weight (360kg), it is not only flexible and convenient to move, but also has no dead pumping.

1.3 Full hose conveying, flow rate is up to 7M3/hour,the machine has a back suction function,when moving the pipe,the material can be sucked back and the empty pipe can be moved more easily,no debris flowing out during the working process

1.4 This machine is safe and convenient to operate, all switch buttons use 24V safety voltage, double control type (remote control and manual).

1.5 Lifting hopper, when moving, the hopper rises. When working, the hopper is placed on the ground so that the materials truck can directly pour the material into the hopper, which saves the labor of feeding.

1.6 Imported motor oil pump control system, anti-phase missing, anti-inversion, anti-leakage, eliminate motor burning.

2 Technical Specifications :

Model	HT-CP7
Pumping Capacity	7.1 M3/Hour
Electricity (Voltage/Hz)	Customized
Power	3.75 Kw
Radiator	Air Cooling
Plastering Distance	Vertical: 15 m
Plastering Distance	Horizontal: 25 m
Max Aggregate Diameter	25 mm
Conveyer Pipe Diameter	75 mm
Weight	360
Dimension	1700x650x110mm
