High Quality KUBOTA Small Tractor L3108

Supplier: Yancheng Harriston Int'l Co.,ltd.
Region: Jiangsu, China
Contact: Ms Aimee Li
Price: $3600.00 / >=10 pieces
Min. Order: 10 pieces

Click here to contact

Product details

Supply Ability:	10 Set/Sets per Month;	Payment Terms:	L/C,T/T,Western Union;
Brand:	kubota;	Packaging Detail:	Container;
Quality:	Best Quality;	Type:	Other;
Product Name:	L3108;	Delivery Detail:	AFTER PAYMENT 15DAYS;
Delivery Time:	Within 15 Days;	Port:	CHINA MAIN PORT;
Use:	Harvesters;	Color:	Red;
Brand Name:	kubota;	Package:	Safe Package;
Place of Origin:	China;	Model Number:	L3108;

High Quality KUBOTA L3108 Small Tractor

Model				L3108
Engine	Type			Kubota D1703-M-DI
	No. of cylinders			3
	Total displacement ( cc )			1647
	Engine gross power ( HP )			31.6@2700 rpm
	Engine net power ( HP )			30.2@2700 rpm
	PTO power ( HP )			26.8@2700 rpm
	Fuel tank capacity ( l )			34
Dimensions	Overall length (without 3P)			2920
	Overall width ( mm)			1305
	Overall height (Top of steering wheel) ( mm)			1500
	Wheelbase ( mm)			1610
	Min. ground clearance ( mm)			340
	Tread	Front ( mm)		1095
		Rear ( mm)		1020
Weight(with mass) ( kg )				1050
Clutch				Dry type Single stage
Traveling System		Tires	Front	7 – 16
			Rear	11.2 – 24
		Steering		Integral type power steering
		Transmission		Gear shift, 8 forward and 4 reverse
		Brake		Wet disk type
		Min. turning radius (with brake) ( m )		2.5
		Traveling speed ( km/h )		21.1
Hydraulic		Hydraulic control system		Position control
		Pump capacity ( l/min )		23.9
		Three point hitch		Category I
		Max. lift force	At lift points ( kg )	906
			24 in. behind ( kg )	651
PTO		PTO (Engine speed) ( rpm )		540 (2,430), 750 (2,596)

We specialized in kubota spare parts, kubota machine ( kubota harvester, kubota transplanter,

kubota tractor).

MACHINE MODEL: 488, 588I, 688Q, 788, 888, DC60, DC68G, DC70, DC95, 704K, 854 ,954,

1004, NSPU68C, NSPU88C, SPW48/68C

KUBOTA machine and Spare Parts are popular in Philippines, Tailand, Vietnam and Sri Lanka

and other countries. So glad to talk with you about Different Kubota machines and Spare Parts.

Yancheng Harriston Machinery Equipment Co. Ltd. Specializes in refrigeration units, agricultural machinery, construction machinery, engine and all kinds of accessories:

1, all independent and non independent refrigeration unit sales, installation, training and customer service service for 9.6meters van truck. Supplying front, top and chassis types to meet the needs of various types of vehicles;

2, Kubota series of machine and accessories’ sales and service, including tractors, harvester, rice transplanter, seeding machine etc.;

3, Yanmar series of machine and accessories’ sales and service, including tractors, harvester, rice transplanter, seeding machine etc.;

4, Cummings full range of engine accessories ‘sales and service, with the East, north, Kang Kang Kang, Xikang and Meikang models;

5, various types of farm implements’ sales and service, including rotary machine, strapping machine, mixing machine, grinder, disc plough, glass mower, seeder, harvester etc.;

6, all kinds of domestic agricultural machinery and equipment ‘s customization and sales, can install nameplate as custom’s request. Including Harvesters, tractors, transplanter, weeding machine, plant protection machinery etc.;

7, Russia MTZ, Romania UTB tractor’s full range of accessories sales;

8, We are as the overseas agent of Japan's mitsuboshi agricultural belt . including SC52 SC59 SC54 SB58 SB59 toothed belt, reliable quality and reasonable price;

9,Can customize all kinds of engine accessories, including the piston, piston rings ,cylinder liner, bearing, crankshaft, cylinder block and cylinder head etc.
