Underground shotcrete machine gunite shotcrete machine
- 600.00 set
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| Application: | Spraying Concrete; | Drive mode: | Diesel Driven; |
| Max. Conveying Distance: | 30m; | Payment Terms: | T/T,Western Union; |
| Color: | Customised; | Work air pressure: | 0.4-0.7Mpa; |
| Name: | Concrete Wet Spraying Machine; | Dimension(L*W*H): | 1800x800x1280mm; |
| Supply Ability: | 1000 Set/Sets per Month; | Port: | Qingdao; |
| Applicable Industries: | Manufacturing Plant,Construction works ,Energy & Mining; | Certification: | ce; |
| Product name: | Concrete Shotcrete Machine; | Condition: | New; |
| After-sales Service Provided: | Free spare parts,Online support; | Warranty: | 1 YEAR; |
| Power(W): | 5.5KW, 5500; | Weight: | 700kg; |
| Output: | 4-5m3/h; | Air Consumption: | 4-5m3/min; |
| Voltage: | 380V,440V,660V,1140, 50Hz/60Hz; | Hose Inner Diameter: | 51; |
| Packaging Detail: | Wooden Case; | Brand Name: | HT; |
| Package: | Wooden Case; |
Product introduction
Using wet concrete jet sprayed concrete operations, can greatly reduce the dust concentration and resilient rate, a spray layer thickness increases, improve production efficiency, guarantee the engineering quality.
Can smoothly enter the special vibration hopper makes concrete batching system, standard of metering pump is to be able to add hardener.
Using low pressure low vortex air transport, close the working principle of the injection overcome the blocking pipe, pulse, the problem such as segregation.
Make the injection material flow uniformity, stability, improve the spray layer material.
Technical parameters
| Model | HT-3PZ | HT-5PZ | HT-6PZ | HT-7PZ | HT-8PZ |
| Production capacity | 3m3/h | 5m3/h | 6m3/h | 7m3/h | 9m3/h |
| The maximum transmission distance | 200m | 200m | 200m | 200m | 200m |
| Applicable material proportioning: cement/sand | 1:3-5 | 1:3-5 | 1:3-5 | 1:3-5 | 1:3-5 |
| Applicable materials water-cement ratio | <0.4 | <0.4 | <0.4 | <0.4 | <0.4 |
| The biggest bone size | 10mm | 15mm | 15mm | 20mm | 20mm |
| Transporting pipe inner | 42 | 51 | 51 | 51/64 | 64 |
| Rotor block diameter | 350mm | 438mm | 438mm | 480mm | 480mm |
| Working pressure | 0.2-0.6MPa | 0.2-0.6MPa | 0.2-0.6MPa | 0.2-0.6MPa | 0.2-0.6MPa |
| blast consumption | 5-6m3/h | 7-8m3/h | 7-8m3/h | 9-10m3/h | 9-10m3/h |
| motor power | 4KW | 5.5KW | 5.5KW | 7.5KW | 7.5KW |
| Level of voltage | 380V,440V,660V,1140, 50Hz/60Hz | ||||
| The weight | 400Kg | 700Kg | 700Kg | 800Kg | 900Kg |
About Us
China Machinery Co. ,Ltd (CNMC), established in 1980, is an important and a large construction engineering equipment joint-stock enterprise Group of Shandong province, It has several wholly-owned subsidiaries, company headquarters is located at Jining Shandong province.
