Full automatic shoelace tipping machine

Supplier: Xuzhou Qixing Machinery Co., Ltd.
Region: Jiangsu, China
Contact: Mr jinlei lv
Price: $3800.00 /set
Min. Order: 1 set

Click here to contact

Product details

Single gross weight:	700 KG;	After-sales Service Provided:	Overseas service center available;
Delivery Detail:	0 days after payment;	Brand Name:	Xuzhou Qixing;
Single package size:	290X130X170 cm;	Place of Origin:	Jiangsu China (Mainland);
Package Type:	plywood case;	Selling Units:	Single item;

Tipping machine is commonly used to tip shoelaces and handbag laces of different materials such as
cotton, acrylic, polypropylene, polyester and so on.

Acetate film will be used as tips.

Model	QXAT-200
Suitable products	Shoelaces
Suitable blade/dies sizes	Φ 2.1, 2.3, 2.5, 2.8, 3.0, 3.2, 3.5, 3.7, 4.0, 4.2, 4.5, 5.0mm (one on machine, one extra as spare)
Suitable rope length	Min.: 420mm; Max.: 2000mm
Suitable acetone film sizes	Width 25, 30, 32, 40, 50mm
Acetone consumption	About 0.5kg/1000 pairs
Horse power	1.5KW
Voltage	380V/50HZ/3PH
Production	10000-12000 pairs/8 hours
Packing	Plywood case
Machine size (with packing)	290012301660mm
Gross Weight	700KG
Delivery time	15 days

Model	QXAT-250
Suitable blade/dies sizes	Φ 2.1, 2.3, 2.5, 2.8, 3.0, 3.2, 3.5, 3.7, 4.0, 4.2, 4.5, 5.0mm (one on machine, one extra as spare)
Suitable rope length	Min.: 420mm; Max.: 2500mm
Suitable acetone film sizes	Width 25, 30, 32, 40, 50mm
Acetone consumption	About 0.5kg/1000 pairs
Horse power	1.5KW
Voltage	380V/50HZ/3PH
Production	10000-12000 pairs/8 hours
Packing	Plywood case
Machine size (with packing)	360012001600mm
Gross Weight	750KG
Delivery time	15-20 days
