Continuous hot dip galvanizing line for plate

Entrance section:

1#(2#) Unwinding → 1#2#Cut Clip Feeding Stick → Convergence Clip Rolling → Welding Machine →

1# tension roller → chemical degreasing → alkali scrubbing → electrolytic degreasing → water scrubbing →1#Water rinse→2# water rinse→3#water rinse→hot air drying→

Process section:

2#tension roller→1#correction→inlet looper→2#correction→3# tension roller→measuring roller→annealing furnace→4# Heat tension roller→zinc pot→quick cooling section→air cooling→tower steering roller→horizontal air cooling→steering roller→water cooling→hot air drying→3#correction→lighting machine→stretching straightening machine→passivation→resistant Fingerprint coating machine→drying furnace→4#correction→export looper→

Exit section:

5# tension roller→oiling→outlet shearing pinch roller→steering pinch roller→EPC correcting coiler→inspection→packaging→warehouse
