TPET full auto napkin machine ET-5830

Supplier: Suzhou Transparent Technology Co.,LTD
Region: Jiangsu, China
Contact: Mr Brent He
Price: $86300.00 /set
Min. Order: 1 set

Click here to contact

Product details

Condition:	New;	Place of Origin:	Jiangsu China;
Power(W):	1.3kw; 3.5kw;	Supply Ability:	300 Set/Sets per Year;
Voltage:	380V 50Hz;	Brand Name:	TPET;
Weight:	860kg;	Production Capacity:	500pcs/h;
Features:	label machine and cutter;	Dimension(LWH):	180105185cm; 210160180cm;
After-sales Service Provided:	Engineers available to service machinery overseas;	Application products:	napkin/surgical cover;
Warranty:	1 Year;	Port:	SHANGHAI;
Machine for:	4-side hemming;	Packaging Detail:	PLYWOOD PACKING;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;

Product Description

Fully-automated dishwash towel machine ET-5830

Application: Surgery operation towels, napkins

Description:

Front part: mainly for length sewing of whole cotton towel, with functions of edge trimming, fabric receiving.

Rear part: high versatile, high-speed, with wide range for adjusting, easy to operate, Including cutting, edge folding, label sewing, thread end trimming and stacking.

Fearures:

Get everything done at one time, including cutting,sewing label, ultrasonic thread hot-cutting,which saves the time of transport.

TECHNICAL PARAMETERS

name	weight	dimensions	feeding frame size	power	voltage	air pressure	components	hour capacity	overlock speed	Label size	Towel size range
vertical sewing (front part)	1200kg	450018001200mm	100018001200mm	2.0kw	220v	/	trimming device, folder, synchronous chain sewing machine,fabric holder	800m/h	4000r/min	/	240-800mm
cross sewing (rear part )	1800kg	340020001900mm	/	5.5kw	220v	>0.6Mpa	3 direct-drive overlock machines including 1 lefthand and 2 righthand, electronic speed synchronous tug	500pcs/h	300-3500r/min	20-40mm wide, 30-100mm long. keep straight or fold by half	18-50cm wide,50-90cm long. edgefold 8-20mm wide
application	suitable for cross hemming home use towels and kerchief in regular size.
