25kva 15kva Transformer 11kv High Voltage Three Phase Power Distribution Transformer

Supplier: Shenzhen Wonstron Technology Co., Limited
Region: Guangdong, China
Contact: Ms Marie Wu
Price: $0.11 /piece
Min. Order: 1 piece

Click here to contact

Product details

Place of Origin:	Guangdong China;	Certification:	CE Rohs;
Output Voltage:	0-10kv;	Bobbin:	EE series and other;
Core:	ferrite, silicon steel sheet;	Port:	shenzhen;
Frequency:	50/60Hz, custom;	Model Number:	TRANS-003;
Insulation grade:	Class B;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,PAYPAL;
Coil Structure:	Toroidal;	Brand Name:	OEM/ODM;
Type:	low frequency transformer;	Phase:	Single;
Coil Number:	Autotransformer;	Usage:	Low Frequency;
Packaging Detail:	Standard Export Carton or as customer required.;	Supply Ability:	10000 Piece/Pieces per Week;
Application:	PCB Assembly transformer module;	Rated voltage:	0-10kv;
Size/Pin:	Custom;

25kva 15kva Transformer 11kv High Voltage Three Phase Power Distribution Transformer

Product Description

1.Competitive price and customerize.
2.Reliable safety approvals with Rohs CE.
3.Good Static Insulation between Primary and Secondary.
4.Small size with low weight, easy to install and maintain.
5.Large transmission power, high frequency or custom, low operating temperature.
6.Possessing of high permeability, high saturation flux density and low loss.
7.Application for power-transfer transformers, choke coils, communication standby
transformers,drive transformer, step-up transformer, LED drive inductance, handheld switch
power supply, charger, etc..

Company Information

Thanks for visiting Wonstron Electronics Co., Ltd!

We are professional Electronics manufacturing company with good reputation in the field.Aim at being a world one-stop service PCBA house Wonstron Electronics.Co.,Ltd (in short Wonstron) keeps pace with update technologies and developing its capacity. Our PCB products range from 1-40 layers with high-frequency and blind/buried vias which are widely applied in automative,industrial,communication,energy fields, Medical,etc.We have six SMT lines in house for EMS service.Now our monthly production capacity can reach 350,000 sq.ft for rigid PCB,100,000 sq.ft for flexible PCB and 100,000,000 points for SMT/EMS

Our Manufacture Capacity:

Item	Mass Production
Max Stencil Size	1560mm*450mm
Min SMT Package	0201
Min IC Pitch	0.3mm
Max PCB Size	1200mm*400mm
Min PCB Thickness	0.35mm
Min Chip Size	001005
Max BGA Size	74mm*74mm
BGA Ball Pitch	1.0-3.00
BGA Ball Diameter	0.2 - 1.0mm
QFP Lead Pitch	0.2mm-2.54mm
SMT Capacity	2 million points per day

Production Lead Time:

Item/Lead Time	Samples	Mass Production
Components	1-2 days	5-10 days
SMT	1-2 days	5-10 days
Delivery	3-5 days	5-20 days

*There will be exception for components with extremely long lead time.

1.One-stop service covering hardware design + software program + PCB layout + PCB assembly + casing
service for customers.

2.More than 20-year experiences with PCB,PCBA production in automatic,auto,medical,industrial con-
trol,security,communications,power supply filed.We help our customers to deal with their difficulties in
the production and cost down by sourcing from China.

3.We provide full BOM sourcing for all kinds of electronic.parts,connectors,plastic mold and cable,etc.
We have most professional component sourcing team and competitive sourcing channels with guarantee
quality.

4.Instant feedback and short delivery time.We provide 24-hour online service for global customers.We
quote BOM within 24 hours and PCB assembly prototype in 5 days.

5.Both prototype and mass production are acceptable.There is no minimum order quantity restrictions.

6.We test both PCB and key components 100% before delivery.Our warranty is 12 months for all the
boards and products.

7.We provide credit to our long-term cooperation customers.

We serve a lot of customers abroad and establish a stable supply relationship in our cooperation.
They visit us to show their projects.Some of them vist us annually for mutual supports.

FAQ

How to contact us?
Answer: You can contact oline or send us email for any question.
How start for inquiry?
Answer: Please send us full manufacture requirements and documents for quotation, i.e. gerber files, BOM, samples if it is necessary.
What are your main services?
Answer: We offer one-stop service of PCB/PCBA manufacture, including PCB design, PCB manufacture, component sourcing, assembly (SMT, DIP,COB).
Do you offer prototype production? What is the lead time?
Answer: We can prepare both sample and mass production. The fastest lead time for double-sided samples is 36 hours. PCBA prototype can be 48 hours including both BOM sourcing and SMT.
How is your quality?
Answer: We test both PCB and key components 100% before delivery. Aim to set up long term cooperation with customers. We provide products with reliable quality.
What is your warranty?
Answer: 6 months
