Factory offer Good quality mild steel welding electrode AWS E6013 J421/ Welding rod E7018 diameter 2.5mm-5.0mm

Supplier: Baoding Xiangxi Wire Drawing Products Co., Ltd.
Region: Hebei, China
Contact: Mr Battier An
Price: $600.00 / >=20 pieces
Min. Order: 20 pieces

Click here to contact

Product details

Diameter:	2.5mm,3.2mm,4.0mm,;	Operating Current:	AC/DC+;
Port:	Tianjin China;	Operating Temperature:	40-240;
GB:	J421;	Length:	300mm,350mm,400mm,;
Packaging Detail:	welding electrode E6013 2.5mm x300/350mm (Packing: 5kg/box+plastic bag, 4boxes/carton=20kg) 3.2mm x 350mm (Packing: 5kg/box+plastic bag, 4boxes/carton=20kg) 4.0mm x 400mm (Packing: 5kg/box+plastic bag, 4boxes/carton=20kg);	Payment Terms:	L/C,T/T;
Place of Origin:	Hebei China;	quality:	low smoke, low spatter;
Application:	light-gauge sheet structures;	Model Number:	E6013;
Brand Name:	ocean bridge;	Material:	carbon steel;
name:	welding electrode AWS E6013;	Supply Ability:	2000 Ton/Tons per Month;
Welding Current:	AC/DC+;	colours:	white;red;black;etc;

mild steel welding rods AWS E6013

Welding Electrodes AWS E6013 is a low carbon steel electrode with high tatania-potassium type coating and suitable for both AC and DC. The electrode is able to provide excellent welding technological performance because the arc is extra stable and spatter loss is negligible, the slag has good fluid and solidified slag is very easy to remove, the manipulate is free and restrike is easy. It can give smooth and beautiful ripples.

This welding rod widely uses in the bridge, the ships, the pressure vessel, industrial fields and so on machine manufacture.
Our factory has the advanced equipments and technology. All the products are strictly examined with all necessary quality testing instruments.
We can supply welding electrode in common sizes: 2.5 x 300/350mm, 3.2 x 350mm, 4.0 x 400mm.

We'd like to cooperate with all sincere and serious customers and welcome you to visit our factory!

Application: Used to weld low carbon steel structures, especially suitable for welding thin flat, intermittent shorter welds, as well as some smooth appearance cover.
CHEMICAL COMPOSITION OF MELTING METAL%

C	Mn	Si	S	P
≤0.10	0.3-0.6	≤0.035	≤0.035	≤0.040

Reference Current

Diameter(mm)		2.0	2.5	3.2	4.0	5.0
Current range(A)	Flat(A)	40~60	60~90	90~130	140~190	190~240
Current range(A)	Vertical&Overhead (A)	30~55	50~80	80~120	120~170	150~200

Kinds of welding rod	Standard model control		Physical and chemical properties
	Standard model control		Chemical composition%					Mechanical Properties
	GB	AWS	C	Si	Mn	S	P	σb(MPa)	σs(Mpa)	δ5(%)	AKV(J)
Low Carbon-steel-Electrode	E4313	E6013	≤0.10	≤0.35	0.3-0.6	≤0.035	≤0.04	≥490	≥400	≥22	(-30)≥27
	E4303	E4303	≤0.12	≤0.25	0.3-0.6	≤0.035	≤0.04	≥490	≥400	≥22	(-30)≥27
	E5018	E7018	≤0.12	≤0.75	≤1.6	≤0.035	≤0.04	490-660	≥510	≥27	(-40)≥47
	E5024	E7024	≤0.12	≤0.60	≤1.25	≤0.035	≤0.04	490-660	≥510	≥27	(-20)≥47
	E5018-1	E7018-1	≤0.15	≤0.75	≤1.6	≤0.035	≤0.035	490-660	≥510	≥27	(-40)≥47
