Mini D330*1000 Performance small normal metal lathe machine for sale

Click here to contact

Product details

Brand Name:	Steel Horse;	Port:	Qingdao;
Certification:	CE;	After-sales Service Provided:	Field maintenance and repair service;
Range of Spindle Speed(r.p.m):	10000;	Type:	Horizontal;
Dimension(LWH):	500300750mm;	Color:	Customized Option;
Width of bed:	4000;	Packaging Detail:	wooden box with steel frame for small metal lathe machine for sale;
Supply Ability:	10 Set/Sets per Day small metal lathe machine for sale;	Condition:	New;
Function:	Threading;	CNC or Not:	Normal;
Place of Origin:	Shandong China (Mainland);	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;
Voltage:	220V,380V;	Model Number:	D330*1000;
Max. Swing Diameter:	330mm;	After-sales Service Provided:	Engineers available to service machinery overseas;
Warranty:	2 Years;	Weight:	105kg/143kg;
HS Code:	84581900;	Year:	2019;
Precision:	0.01mm;	Power(W):	550,750W;
Automatic Grade:	Manual;

D330*1000 Performance small metal lathe machine for sale

Product Description

D330 X 1000 Metal Lathe Machine

Main Feature :

Convincing Arguments: Quality, Efficiency and Price

- Connecting Voltage is Three Phase 400V or Single Phase 240V ( optional )

- Hardened and ground bed guideways

- Camlock spindle seat DIN ISO702-2 NR.4

- Guaranteed true running accuracy of the spindle nose of better than 0.015mm

- Electrical system with Siemens components

- Acceptance certificate and Easy-To-Operate

- All guideways are adjustable and High working accuracy

- Cast-iron bed, double V-guide, hardened and ground

- Clearly-arranged Keyboard

- Made in ISO9001 Factory with CE Safety certification

- Emergency-stop push button, protective motor switch, lockable main switch

- Right-handed /left-handed rotation on the bed slide switchable via stem

- Chip protection at the top slide and Cover for leading spindle

- Machine substructure including tool compartment

- Certificate of Original (CO, FORM A, FORM E, FORM F )

Product Name :	13 X 40 inch Metal Bench Lathe Machine
Product Item :	MM-D330 X 1000
Max Swing over Bed :	Ø 330 mm
Swing over Cross Slide :	Ø 198 mm
Distance between centers :	1000 mm
Turning Diameter in the Bed Bridge :	Ø 476 mm
Length of Bed Bridge :	210 mm
Centre Height :	165 mm
Spindle Bore :	Ø 38 mm
Spindle Taper :	MT 5
Tailstock Taper :	MT 3
Spindle Speed :	70—2000 RPM
Number of Steps :	8 Steps
Pitch-Metric in the range of :	0.4—7mm ( 26 thread pitches )
Pitch-Inch in the range of :	4—56 TPI ( 34 thread pitches )
Longitudinal feed in the range of :	0.052—1.392 mm/rev (40 feeds)
Transverse feed in the range of :	0.014—0.380 mm/rev (40 feeds)
Spindle Seat :	Camlock DIN ISO702-2 NR.4
Spindle hole, rod passage :	Ø 38 mm
Travel of Top slide :	95 mm
Travel of Cross slide :	170 mm
Tailstock Sleeve Travel :	126 mm
Tailstock Sleeve Diameter :	Ø 45 mm
Main Motor :	1500W powerful motor
Quadruple tool holder seat height :	16 X 16 mm
Connecting Voltage :	Single Phase 240V or Three phase 400V
Gross Weight :	550 KGS
Packing Size:	1930 X 755 X 1300 mm
Standard Accessory :	Three-Jaw Chuck Ø 160mm Complete change gear kit Quadruple tool holder Revolving centre Chip tray Tools and Tool box
