PNOZ s5 777301 Safety relay PNOZsigma (standalone),

Supplier: Shenzhen Haiyue Machine And Electronic Equipment Co., Ltd.
Region: Guangdong, China
Contact: Ms Phoenix Cheng
Price: $95.00 / >=5 pieces
Min. Order: 5 pieces

Click here to contact

Product details

technical support:	Yes	Warranty:	1 year modification period
model:	PNOZ X2.8P	Origin:	Germany
Package Preview:		describe:	Industrial control equipment
delivery time:	stock available	application:	Industry, etc.
Health status:	100% original	Supply capacity:	10,000 pieces per day
high quality:	Original German made	payment terms:	T/T, Alibaba Trade Assurance
Packaging Details:	Standard export packaging	Material:	Metal

PNOZ X2.8P 24VACDC 3n/o 1n/c Article number: 777301

Safety relay (stand-alone), Input: 1/2 channel wiring, with/without contact short-circuit detection, Output: 3 N/O, 1 N/C, Auto/Manual start, UB 24 V AC/DC, Width: 22.5 mm, Plug-in screw terminals, Emergency stop monitoring, Safety door.

Electrical data
Supply voltage (V)	24 volts
Supply voltage type U1	AC/DC
AC power consumption	5.5
DC power consumption	2.5 W
enter
Input quantity	2
Semiconductor output
Semiconductor output quantity	0
Relay output
Use category AC/DC1 bracket.	EN 60947-4-1
Voltage AC1 is continuously applied safely.	240
Maximum current AC1 is safe and continuous.	6
Voltage DC1 is safely continuous.	twenty four
Maximum current DC1 can be safely sustained.	6
Use category AC15/DC13sta.	EN 60947-5-1
Voltage AC15 safe and continuous.	230
Maximum current AC15 safe continuous.	5
Voltage DC13 is safe and continuous.	twenty four
Safety contacts: UL specified AC	240 VAC GU (same polarity)
Safety Contact: Pilot Responsibilities	INR 300
Relay contact material	Silver Copper Nickel
Additional relay contact information	+ 0.2 µm Gold
