dongfeng 40hp 4wd farm tractor 50hp, 60hp, 65hp, 70hp 4wd agricultural farm tractor

Supplier: Zhengzhou Dongfeng Mid-South Enterprise Co., Ltd.
Region: Henan, China
Contact: Ms Emmy Sun
Price: $5400.00 / >=2 units
Min. Order: 2 units

Click here to contact

Product details

Port:	Qingdao;	Options:	Driver Cabin, A/C, etc;
By wheel:	2WD/4WD;	Brake:	External Shoe;
Differential Lock:	Jaw lock;	Packaging Detail:	nude;
Supply Ability:	500 Unit/Units per Month;	Engine type:	3Cylinder Engine;
Usage:	Farm Tractor;	Color:	Green Red Blue as request;
After-sales Service Provided:	Engineers available to service machinery overseas;	Differential:	Bevel Gear;
Product name:	farm tractor;	Delivery Detail:	Shipped in 30 days after payment;
Condition:	New;	Brand Name:	Dongfeng;
Place of Origin:	China (Mainland);	Type:	Wheel Tractor;
Implements:	Plough Harrow Cultivator Trailer;	Clutch:	Linkage type, double-acting clutch;
Model Number:	DF304;	Drive type:	2WD, 4WD;
Power(W):	300;	Certificate:	CE;
Payment Terms:	L/C,T/T;	Drive Type:	Gear Drive;

Best quality 30hp 4x4 4WD farm tractor with bucket front loader

1. Introduction:

Dongfeng Wheeled Tractor, is developed on the basis of the Italian wheeled tractor chassis technology, adopting the British technology-based 6-cylinder turbocharged engine. The machine body has a streamline configuration. It is low in specific fuel consumption and better in power economic efficiency. It has multiple gears and a wide speed range. Besides, it is flexible in steering and easy to operate.

2. Main Features:

♦ Specially used in mountain areas and muddy roads;

♦ 4 in1 combined light is used in the front, and modular lights can provide good lighting at night;

♦ It has the characteristics of high transmission efficiency, low tremble, high traction, high adaptability and easy start;

♦ Hydraulic output interface can make direct connection with the dump trailer, mower, backhoe, plough, etc;

♦ This series of tractor can have many different configurations according to customer’s demands.

1) Horse Power: 20hp to 220hp

2) Wheel Drive: 2WD and 4WD

If you need other requirement, please inform us, we will do our best to support you.

3. Specifications of Farm tractor DF-300/ DF-304:

Tractor Parameters	Model		DF-300		DF-304

	Drive Type		2WD		4WD
	Overall Dimensions L×W×H(mm):		3290×1485×1620
	Wheel Track(mm)	Front	1100, 1200, 1300	1200
		Rear	1100,1200,1300,1400
	Wheel Base(mm)		1710		1710
	Ground Clearance (mm)		378		358
	Rated Traction Force(N)	In Paddy Fields	4200		4950
		In Dry Fields	6300		6940
	Construction Mass(kg)		1235		1350
	Min. Turning Radius(m)		2.5
	Theoretical Speed (km/h)	Forward	1.73, 2.85, 4.59, 6.17, 8.98, 14.79, 23.80, 31.96
		Reverse	2.28, 11.83
Engine Specifications	Model		ZN390T
	Type		3-cylinder, Vertical, in-line cylinder arrangement, radiator cooling, 4-stroke cycle, direct injection
	Rated Power(kW)		22.1
	Rated Speed(rpm)		2500
	Bore ×Stroke(mm)		90×95
	Total Displacement(L)		1.812
Drive System	Clutch		Linkage type, double-acting clutch
	Gear Box		(4+1)×2
	Main Drive		One Pair of Spiral Bevel Gears
	Differential		Bevel Gear
	Differential Lock		Jaw Lock
	Final Transmissions		Spur Gear, External Gearing
Traveling Mechanism	Tire	Front	5.50-12		6.50-16
		Rear	11.2-24		11.2-24
	Steering Gear		Full hydraulic power steering
	Brake		Shoe brake
	Hydraulic System	Lifting Capacity at 610 mm Behind Lift Point(kg)	496
		3-Point Suspension	Category: Ⅰ
	P.T.O. Shaft	Rotating Speed(rpm)	540/1000
		Spline Size	6-35 Rectangular Spline

4. Different models for choosen:

5. More pictures
