www.ingersollrandproducts.com/en/air-compressor

Supplier: Shanghai Compressor Service Co., Ltd.
Region: Shanghai, China
Contact: Mr Bill Shaw
Price: $60000.00 /unit
Min. Order: 1 unit

Click here to contact

Product details

Voltage:	380V 460V 50HZ 60HZ;	Type:	Rotary;
Configuration:	Stationary;	Warranty:	2 Years;
Lubrication Style:	Contracting Services;	Weight:	1632kgs (3598lb);
Payment Terms:	L/C,T/T,Western Union;	Port:	SHANGHAI,CHIINA;
Supply Ability:	15 Unit/Units per Month;	Mute:	No;
Dimension(LWH):	208 (82) x 112 (44) x 203 (80);	Certification:	TUV;
Brand Name:	INGERSOLL RAND;	After-sales Service Provided:	Overseas service center available;
Packaging Detail:	WOODEN CASE IN LCL WOODEN PALLET IN FCL;	Place of Origin:	Shanghai China (Mainland);
Power Source:	AC Power;	Condition:	New;

www.ingersollrandproducts.com/en/air-compressor

Case, Air compressor+air dryer+inline filter+air tank/ Ingersoll Rand air solution system/compressed air supply system

We are commissioning two new Ingersoll Rand R55 75HP compressors this morning. One of these compressors is a fixed speed and the other is an energy efficient variable speed. The industry leading onboard Xe controllers on these units allow the two machines to function seamlessly for maximum efficiency with a single ethernet cable. Another fine example of state of the art equipment and engineering services

Ingersoll Rand R55n-R75n Medium Rotary Screw Air Compressor

New installation of our new best in class RS Series air compressor systems for a distribution center

The Next Generation R-Series was designed with the intent of maximizing your company's profits. Bringing you class leading air flow as well as world class efficiency, the Next Gen RSeries will bring you the most value for your dollar. Designed to maximize your up-time and minimize your out of pocket expenses by bringing you a service friendly package layout as well as state-of-the-art reliability features. The RS30-37i comes standard with an Intelligent Microprocessor Controller allowing you to talk to your system like never before and know exactly what is going on in your system.

Features

Smart, Energy Efficient Controls
Industry-leading performance delivers more air for less horsepower, saving thousands of dollars per year on energy.
Installation Close to Point-of-Use
Whisper quiet operation allows for installation closer to point-of-use, reducing costs and ensuring a better & safer work environment.
Closely Maintained Pressure
Reducing discharge pressure and avoiding excessive pressure bands increases downstream tool and equipment life.
70% Fewer Connections
Smart integration eliminates leaks and pressure drops maximizing reliability.
Compact Footprint Design
Small footprint frees up valuable floor space and reduces install costs.
Optional Total Air System Package
Complete integrated air treatment package.

Technical Details

40 horsepower
Dimensions: 72L x 42W x 60H

Standard Models

196 ACFM with 115 max PSI
184 ACFM with 125 max PSI
Weight 2304

TAS Models

196 ACFM with 103 max PSI
184 ACFM with 118 max PSI
Weight: 2535 pounds

View Brochure RS30i/RS37i

View Tech Data RS30i/RS37i

New installation of a Premium Efficiency Ingersoll Rand Nirvana R190ne, 250hp Variable Speed Drive Rotary Screw Air Compressor at a High Tech Manufacturer

R110i 150hp rotary screw air compressor/ingersoll rand lubricated compressor with oil inject/ soft start

installing a new Ingersoll Rand R90ie 125HP Premium Efficiency Two-Stage Rotary Screw Air Compressor today at a gas fired power plant

R110i Compressed air compliance with FDA regulations is key and ASPS engineers can assist your plant meet and exceed those requirements with certified testing

Contracting Services

Installations

Ingersoll Rand Air Solutions Group now offers a complete range of services in compressed air system installation and integration. From the smallest air-cooled reciprocating air system to the largest water-cooled centrifugal installation, Ingersoll Rand has the capability to manage and implement a complete compressed air system.

Benefits include

Fully Integrated Project Management
Single Source Responsibility
Air System Design
Fully Integrated Support
Compressed Air System Expertise
Air System Optimization

Compressed Air Expertise – Ingersoll Rand’s 100 plus years as the leader in the compressed air business, allows you to benefit from our experience. Ingersoll Rand knows how to design, install, and maintain compressed air systems. Ingersoll Rand’s knowledge of compressed air systems allows them to offer central control sequencing, and monitoring systems.

Single Source Responsibility – Ingersoll Rand can design the compressed air system, supply the compressed air equipment and install the completed system. This allows you to have only one contact to satisfy all your compressed air needs. Ingersoll Rand’s breadth of services allows us to accept complete responsibility and insure your satisfaction.

Air System Design – The proper initial design of the compressed air system will result in superior compressed air system operation. Ingersoll Rand can offer air system design that will meet your present needs and offer flexibility for future expansions. We specialize in multiple types of air compression technologies, and are skilled in selecting the proper equipment design and layout for your operation.

Fully Integrated Project Management – Ingersoll Rand’s Air Solution Group has the ability to handle any type of compressed air system installation. A Project Manager oversees and instructs the complete project, ensuring proper installation and efficient operation.

Fully Integrated Support – Ingersoll Rand is able to supply all necessary support for your air system. We can design, supply, install, repair, and maintain your system. We supply parts and service for all makes and models of air compressors and accessories. With our AirCare compressor maintenance inspection program, extended warranties are available to protect your investment.

Air System Optimization – The ability to optimize a compressed air system comes from years of being in the business. Ingersoll Rand can optimize your system to save you energy costs, reduce maintenance and provide a reliable air system. Optimization involves ensuring that each piece of equipment in the air system is working at properly and each component is tuned to work efficiently with all the parts of the system.

For your compressed air system, Ingersoll Rand is your single source provider, with:

Design service - determine system requirements, equipment selection, and air system layout.
Equipment provider - compressors, dryers, cooling towers, receiver tanks

Project management - equipment, building, piping, complete installation and commissioning

Maintenance and operation services - long term source for parts and maintenance

IRN55K-OF IRN75K-OF IRN90K-OF

Ingersoll Rand Rotary Screw Air Compressor Nirvana Variable-Speed Drive Oil Free Compressor

Ingersoll Rand Air Compressors and Services

Oil-Free Rotary Screw Air Compressors

Nirvana Variable Speed Oil-Free Rotary Screw Air Compressors 55-75 kW

Nirvana oil-free air compressors, with a matching variable speed inverter and hybrid permanent magnet (HPM®)motor, provide unparalleled energy efficiency at all speeds along with superb reliability. They deliver ISO 8573-1:2010 Class 0 certified 100% oil-free air for the most critical applications. There are no motor bearings, pulleys, belts, couplings or motor shaft seals to wear out, leak or need replacing. Nirvana will lower your operating costs with its dynamic efficiency -- a truly transcendent technology!

Ingersoll Rand offers a wide portfolio of oil-free products that will adapt to your industry and application. From the industry that requires large volumes of flow, to the industries with a fluctuating demand that requires the use of the Nirvana oil-free VSD compressor, Ingersoll Rand will assess and propose the best oil-free solution for your needs. Ingersoll Rand will offer his expertise also for the low pressure application.

Key benefits:

Increasing the productivity of your installation, with optimized compressed air solutions adapted and designed to match the needs of our customers;
Peace of mind – zero risk of contamination of your final product;
Robustness and reliability for harsh environments thanks to trusted and world class suppliers and the use of the highest quality materials.

Quality is not an option, it is essential:

Regulatory compliance: Strict legislation exists in many countries controlling the use of compressed air in sensitive industries such as Food & Beverage or Pharmaceutical;
Peace of mind: The use of an oil-free Class 0 certified compressor guarantees contamination-free air and ensures your total peace of mind;
Reliability and productivity: Top quality air (oil-free Class 0 air & -40°C PDP) protects sensitive downstream equipment, for reliability, low maintenance and long life.

Reduced cost of ownership:

Compressed air solutions using oil-free technology optimize productivity in your operation;
Thanks to our patented rotor coating (UltraCoat®), compressor efficiency and reliability are assured throughout their working life;
Active carbon filters are not required, eliminating the waste of energy in pressure drop;
Maintenance
Our equipment is designed specifically to make maintenance easy by providing clear access to consumable components.

Reciprocating
Rotary Screw
Centrifugal
Oil Free Rotary Screw
Dryers
Filters
Controls
PET Blow Molding

Nirvana Variable Speed Oil-Free Rotary Screw Air Compressors 37-45 kW

FEATURES:

100% Oil-Free Air: Meets ISO 8573-1:2001 Class 0 specifies air quality standards for processes within the food and beverage, pharmaceutical, textile, and electronics industries
Lower Energy Costs: Combination of variable speed operation and the Nirvana HPM® motor, along with an advanced system controller, delivers ultra-efficient peformance
Enhanced Reliability: Stainless steel components, dual-vented seals, and precision machined-rotors with advanced UltraCoat protection ensure trouble-free operation
Reduced Lubricant Change-Out: Industry-leading Ultra Coolant delivers up to 8,000 hours of lubricant run time, as much as 8 times the life of conventional lubricants
High Ambient Operation: Long-life components are designed to withstand 46 ºC maximum ambient temperature

MPDEL	CAPACITY		PRESSURE		COOLING
MPDEL	m3/min	ft3/min	bar(g)	psi(g)	A/C / W/C
IRN55K-OF	3.8-10.7	134-378	7	101	A/C
	3.7-10.2	131-360	7.5	109
	3.8-9.8	134-346	8	116
	3.9-9.4	138-332	8.5	123
	3.9-8.5	138-300	10	145
	3.8-10.7	134-378	7	101	W/C
	3.7-10.2	131-360	7.5	109
	3.8-9.8	134-346	8	116
	3.9-9.4	138-332	8.5	123
	3.9-8.5	138-300	10	145
IRN75K-OF	3.8-14	134-494	7	101	A/C
	3.8-13.5	134-477	7.5	109
	3.9-12.5	138-441	8	116
	3.9-12.2	138-431	8.5	123
	4.0-11.7	141-413	10	145
	3.8-14	134-494	7	101	W/C
	3.8-13.5	134-477	7.5	109
	3.9-12.5	138-441	8	116
	3.9-12.2	138-431	8.5	123
	4.0-11.7	141-413	10	145
IRN90K-OF	9.1-18.0	151-299	7	101	A/C
	9.3-17.1	155-285	7.5	109
	9.3-16.5	155-275	8	116
	9.2-15.3	153-255	8.5	123
	9.6-14.0	160-234	10	145
	9.1-18.0	151-299	7	101	W/C
	9.3-17.1	155-285	7.5	109
	9.3-16.5	155-275	8	116
	9.2-15.3	153-255	8.5	123
	9.6-14.0	160-234	10	145

Other Products

18BARG, INGERSOLL RAND CHINA FILTER, COMPRESSED AIR TREATMENT, HIGH-PRESSURE AIR FILTER

$200.00 / unit
