Buffer Printer Odorless Pad Printing Machine Sealed Ink Cup Toy Card Pad Printing Machine

Supplier: Ruian Chengyue Electromechanical Co., Ltd.
Region: Zhejiang, China
Contact: Ms Cherry Cao
Price: $1350.00 / 1 - 4 sets
$1150.00 / 5 - 9 sets
$998.00 / >=10 sets
Min. Order: 1 set

Click here to contact

Product details

Maximum printing speed:	1800 piece hours	Plate type:	Printing machine
Packaging Details:	wooden box	Marketing Type:	2020 New Products
port:	Ningbo	Automatic level:	semi-automatic
weight:	65 kg	Core component warranty:	1 year
Key words:	Tampon machine	payment terms:	L/C, Western Union, T/T
usage:	Pad printer, card printer	Showroom location:	not any
air pressure:	5-7 bars	Printing area:	75*75mm
Voltage:	220V/110V	Dimensions (LWH):	507575 cm
Printing color:	1 color	Supply capacity:	1000 sets per month
Application fields:	pen toy. Keyboards. Plastic and metal products	Product Description:	1 color closed cup pad printer
Origin:	Zhejiang, China	Mechanical test report:	if
Main selling points:	environmentally friendly	Warranty:	1 year
Health status:	new	Colors and Pages:	monochrome
Core components:	PLC	brand:	Cy
Video outbound inspection:	if	Applicable industries:	printing shop
Package preview:		type:	Printing machine
application:	Small Letterpress Press	product name:	Printing machine
Operation:	pneumatic

Product Description

1. Microcontroller program operation, multiple printing mode options, manual, semi-automatic, fully automatic 2. Fast printing speed. The combination of multiple machines can become an assembly line 3. Full cast aluminum body, metal paint surface 4. The position of the worktable, rubber head and steel plate can be adjusted at any position on the XYZ axis 5. The ink-absorbing printing pressure rubber head can be adjusted independently 6. Scraping The ink stroke is adjustable 7. It has the function of automatic sliding before and after ink uniformity to prevent the ink from drying 8. The speed of each cylinder can be adjusted independently 9. RubberHead fixation: wood screw locking10.Fixture material selection: Atomic gray aluminum | Processing | Bakelite | | Plastic steel11. The whole machine runs fast, stable and low noise 12.Fixture fixing method: T-slot table, pressure code compression

13. Starting method: panel | pedal switch 14. Working mode of scraper: electronic valve drives cylinder up and down 15. Pressure control of scraper: constant pressure of pressure regulating valve

Specification

type	Printing machine
Ink cup size	70 or 90 mm
printing area	55 or 75mm
printing speed	1800 per hour
print height	180mm
power supply	220V/110V
Gas source	0.5~0.8Mpa
aspect	507575cm
weight	65 kg
Warranty	1 year
coloring page	monochrome
Certificate	CE

Instructions

1.	Movie	Design Your Logo From Your Computer	personal computer
2.	template	sign on steel plate	personal computer
3.	ink	various printing materials	Kilogram
4.	Thinner	Cyclohexanone	Kilogram
5.	washing water	718	Kilogram
6.	eraser	According to the shape and hardness of the object	personal computer
7.	blade	For 4", 6", 8", 10" cartridge types	personal computer
8.	ink cup ring	D=70mm, 90mm	personal computer
9.	fixture	by object	put
10.	Air compressor	3HP/2.2kW	put
