JA,GCL,Q-cell,Trina ,Risen,CSUN ,Sun tech A grade 325W,330W,335W,340W poly solar panel

Supplier: Shenzhen Dingjing Industry Development Corporation Limited
Region: Guangdong, China
Contact: Mr. charlie zha
Price: $0.21 / >=10000 pieces
Min. Order: 10000 pieces

Click here to contact

Product details

Certificate:	TUV/IEC61215/IEC61730/CEC/CE/PID/ISO;	Brand Name:	Topsky;
Output Cables:	TUV (2Pfg1169:2007);	No.of cells:	72(6x12)pcs;
Weight:	25.9 kgs (57.1 lbs.);	Junction Box:	IP68 rated {3 bypass diodes);
Frame:	Anodized aluminium alloy;	Solar Cell:	Polycrystalline silicon 6 inches;
Product name:	330W solar panel price;	Payment Terms:	L/C,T/T,Western Union,MoneyGram;
Front Glass:	4.0 mm (0.16 inches) tempered glass;	Size:	1960 x 992 x 40mm;
Packaging Detail:	Standard foreign trade export box, 26pcs/carton+wooden pallet;	Model Number:	jinko,JA,GCL,CSUN,Risen,Sun tech;
Connectors:	MC4 compatible;	Place of Origin:	Guangdong China (Mainland);
Type:	Standard Solar Panel;	Port:	Shenzhen/Hongkong;
Supply Ability:	30000000 Watt/Watts per Month suntech solar panel price;

We established long term agreement with JA ,Q-cell ,GCL,Jinko ,Risen,Sun tech CSUN brand as their distributor and can supply 325W ,330W,335W ,340W Poly solar panels and stock with very competitive price.

Feature:

1)Global, Tier 1 bankable brand, with independently certified
state-of-the-art automated manufacturing
2)Photon independent field testing
3)Industry leading lowest thermal co-efficient of power
4) Industry leading 12 years product warranty
5)Excellent low irradiance performance
6)Positive tight power tolerance of 3%
7) Excellent PID resistance
8)Dual stage 100% EL Inspection warranting defect-free product
9) Module Imp binning radically reduces string mismatch losses

10) Warranted reliability and stringent quality assurances well beyond
certified requirements

KEY SALIENT FEATURES
Anti-reflective & anti-soiling surface minimise power loss from dirt and dust

dirt and dust

Severe salt mist, ammonia & blown sand resistance, for seaside farm and desert environments

Excellent mechanical load 2400Pa & snow load 5400Pa resistance

Electrical Characteristics

Product Characteristics

Model No.

TP-320P

TP-325P

TP-330P

TP-335P

TP-340P

Warranty

Product Warranty

25 Years

Power Warranty

10 Years of 90% Output Power, 25 Years of 80% Output Power

Electrical Data at STC

Maximum Power (Pmax)

320 Wp

325 Wp

330 Wp

335 Wp

340 Wp

Voltage at Maximum Power (Vmpp)

37.4 V

37.6 V

37.8 V

38 V

38.2 V

Current at Maximum Power (Impp)

8.56 A

8.65 A

8.74 A

8.83 A

8.92 A

Open Circuit Voltage (Voc)

45.1 V

45.3 V

45.6 V

45.9 V

46.2 V

Short Circuit Current (Isc)

8.76 A

8.84 A

8.91 A

8.96 A

9.01 A

Panel Efficiency

16.5 %

16.75 %

17 %

17.25 %

17.5 %

Power Tolerance (Positive)

+ 3 %

Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m², cell temperature 25°C

NOCT: Irradiance 800 W/m², ambient temperature 20 °C, AM=1.5, wind speed 1 m/s;

Maximum Power (Pmax)

237 Wp

241 Wp

245 Wp

250 Wp

255 Wp

Voltage at Maximum Power (Vmpp)

33.5 V

33.7 V

34 V

34.4 V

34.7 V

Current at Maximum Power (Impp)

6.5 A

6.56 A

6.62 A

6.68 A

6.71 A

Open Circuit Voltage (Voc)

41.9 V

42.3 V

42.4 V

42.7 V

42.8 V

Short Circuit Current (Isc)

7.09 A

7.16 A

7.21 A

7.26 A

7.28 A

Temperature

45±2 °C

Nominal Operating Cell Temperature (NOCT): 800W/m², AM 1.5, windspeed 1m/s,ambient temperature 20°C

Thermal Ratings

Operating Temperature Range

-40~85 °C

Temperature Coefficient of Pmax

-0.41 %/°C

Temperature Coefficient of Voc

-0.31 %/°C

Temperature Coefficient of Isc

0.06 %/°C

Maximum Ratings

Maximum System Voltage

1000 V

Series Fuse Rating

15 A

Material Data

Panel Dimension (H/W/D)

1956x992x40 mm

Weight

22.5 kg

Cell Type

Polycrystalline

Cell Size

156.75×156.75 mm

Cell Number

Glass Type

Tempered, High Transmittance, Low Iron

Glass Thickness

4 mm

Encapsulant Type

EVA

Back Cover Type

TPT

Frame Type

Anodized Aluminium Alloy

Junction Box Protection Class

IP 67

Connector Type

MC4

Cable Crossection

4 mm²

Cable Length

900 mm

Best in Class AAA solar simulator (IEC 60904-9) used, power measurement uncertainty is within +/- 3%

Mechanical Characteristics

Solar Cell	Polycrystalline silicon 6 inches
No. of Cells	72(6x12)
Dimensions	1960 x 992 x 40mm (77.2 x 39.1 x 1.6 inches)
Weight	25.9 kgs (57.1 lbs.)
Front Glass	4.0 mm (0.16 inches) tempered glass
Frame	Anodized aluminium alloy
Junction Box	IP68 rated {3 bypass diodes)
Output Cables	TUV (2Pfg1169:2007)
	4.0 mm2(0.006 inches2), symmetrical lengths (-) 1100mm (43.3 inches) and (+) 1100 mm (43.3 inches)
Connectors	MC4 compatible
