projector type
|
DLP chip x 1, DLP monitor
|
|
chip size
|
0.67''
|
|
original resolution
|
1920×1200
|
|
brightness
|
15,000 lumens
|
|
Uniformity*2
|
90%
|
|
Contrast*2
|
12000:1
|
|
aspect ratio
|
16:10: native / 4:3 compatible
|
|
light source |
type
|
RGBL laser technology
|
|
Life
|
Standard: 20000 hours Eco Mode: 25000 hours
|
| |
projection lens
|
A06: 1.22-1.53:1 (standard)/A13 2.90-5.50:1/A1 0.57:1
|
| |
throw ratio
|
(0.36~5.50)
|
| |
h
|
±20°
|
| |
V
|
±20°
|
|
|
ceiling, front, back
|
|
DVI-Dx1
|
|
HDMI 1.4 (support HDCP*3) x1
|
|
15-pin Mini Dsubx1
|
|
HDBaseT*4x1
|
|
Wired remote control x1 3.5mm
|
|
RJ45×1 (LAN control)
|
|
RS232(D-sub 9pin)x1
|
|
Mini USBx1
|
|
USB-A x1
|
|
output
|
15-pin Mini Dsubx1
|
|
HDMI 1.4 (support HDCP*3) OUTx1
|
| |
3D sync x1
|
|
Power input (voltage & frequency)
|
100-240V AC±10%, 50/60Hz
|
|
energy consumption
|
Normal: 770W, Energy Saving: 395W
|
|
case material
|
molded plastic
|
|
Standby power consumption
|
<0.5W
|
|
Dimensions LxWxH
|
484mm(W)×519mm(D)×181mm(H)
|
|
net weight
|
about 25kg
|
|
noise
|
Normal: 35dB ECO: 33dB
|
|
Working temperature*5 |
high altitude
|
0m-2500m (>1500m use high altitude mode)
|
|
temperature
|
5-40℃,
|
|
humidity
|
10%-85%
|
|
Accessories
|
AAA battery × 2, remote control × 1, power cord × 1, VGAC cable × 1, CD-ROM (user manual) × 1, quick installation manual, warranty card, lens cover
|
