Energy Absorbing Vibration Isolation Shock Resistant Spiral Wire Rope Vibration Isolator
-
Supplier: Shaanxi Hybono Electronic Technology Co., Ltd. -
Region: Shaanxi, China -
Contact: Ms kelly li -
Price: $30.00 /piece -
Min. Order: 1 piece
Product details
| After warranty service: | online support | Mechanical test report: | if |
| Origin: | Shanxi Province, China | After-sales service provided: | online support |
| port: | Shanghai, Tianjin, Qingdao | Health status: | new |
| Model: | Hybono | Material: | Aluminum or stainless steel, steel wire |
| Warranty: | 1 year | Local service location: | not any |
| product name: | Wire Rope Isolator | Showroom location: | not any |
| Core components: | steel wire | Temperature resistance: | -75-175(℃) |
| type: | shock absorber | Supply capacity: | 1000 pieces per week |
| Applicable industries: | Shipbuilding, Navy, Military Vehicles, Energy | brand: | Hybono |
| Video shipment inspection: | not available | Weight (kg): | 10 |
| brand: | Hybono, Hybono | payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram |
| Marketing Type: | New Products 2020 | Noise reduction effect: | Efficient |
| Packaging Details: | wooden box or carton |
| Model | load capacity(kg) | Dimensions (mm) | ||||
| large | A | h | W | rice | ||
| WR2-100 | 12-15 | 112 | 100 | twenty three | 28 | M6 |
| WR2-200 | 8-12 | 25 | 31 | M6 | ||
| WR2-300 | 6-8 | 28 | 33 | M6 | ||
| WR2-400 | 4-6 | 33 | 38 | M6 | ||
| WR2-500 | 3-5 | 36 | 41 | M6 | ||
| WR2-600 | 2.5-4 | 38 | 43 | M6 | ||
| WR3-100 | 20-25 | 127 | 114 | 28 | 36 | M6 |
| WR3-200 | 15-20 | 31 | 38 | M6 | ||
| WR3-300 | 13-15 | 33 | 41 | M6 | ||
| WR3-400 | 10-13 | 36 | 43 | M6 | ||
| WR3-500 | 8-10 | 38 | 46 | M6 | ||
| WR3-600 | 5-8 | 41 | 48 | M6 | ||
| WR4-100 | 36-60 | 127 | 114 | 28 | 37 | M8 |
| WR4-200 | 32-41 | 31 | 37 | M8 | ||
| WR4-300 | 20-28 | 127 | 114 | 33 | 42 | M8 |
| WR4-400 | 15-20 | 36 | 45 | M8 | ||
| WR4-500 | 10-15 | 38 | 47 | M8 | ||
| WR4-600 | 5-10 | 41 | 50 | M8 | ||
| WR5-100 | 73-95 | 31 | 36 | M8 | ||
| WR5-200 | 57-73 | 33 | 38 | M8 | ||
| WR5-300 | 43-57 | 127 | 114 | 36 | 41 | M8 |
| WR5-400 | 32-43 | 38 | 43 | M8 | ||
| WR5-500 | 25-32 | 41 | 46 | M8 | ||
| WR5-600 | 18-25 | 43 | 48 | M8 | ||
