brazing rod Phosphor copper BCuP-2 brazing rod Products from Anhui Huazhong Welding Industry Co., Ltd.

Product Details

Flux content:	No	Supply capacity:	1000 kg per day
Packaging Details:	Standard export packing, or as required	model:	BCuP2-----BCuP9
color:	bright copper	Processing:	Accept OEM
Certificate:	SGS certification	sample:	free sample
application:	used as a deoxidizer	diameter:	As required
payment terms:	L/C, T/T, Western Union	Melting point:	643
brand:	Central China	weight:	1 kg
product name:	Copper Phosphorus Electrode	port:	Shanghai
Material:	copper alloy	place of origin; place of origin:	Anhui, China

All products

Selling

Copper Phosphorus Electrode

AWS 5.8 more details

Brass Brazing Rod

AWS 5.8 RBCuZn-C more details

Silver Brazing Rod/Ring

AWS 5.8 BAg-7 more details

Product Description

BCuP-2 0 silver phosphorus copper brazing rod

Anhui Huazhong Welding Material Manufacturing Co., Ltd.

Product parameters

describe:
PhosCopper 0 is mainly used for copper-to-copper connections on vibration-free joints. joining is very effective Tight-fitting copper tubing and piping widely used in the heating, ventilation and air conditioning (HVAC) industry to Make preformed rings for the evaporator/condenser. PhosCopper 0 should not be used on ferrous metals or containing more More than 10% nickel because phosphorus becomes embrittled by reaction with iron or nickel. PhosCopper 0 in Brazing temperature and will penetrate the joint with very small gaps. The best results are obtained with clearance 0.001-0.003". PhosCopper 0 melts almost completely at 1350°F (732°C). Best results are obtained with light brazing higher than this temperature.
application:
Brazing copper and copper alloys, as well as brass, bronze, silver, tungsten and molybdenum.
Hertz	Melting range (ºC)	chemical composition%
Hertz	Melting range (ºC)			copper	phosphorus	other
HZ-CuP6	710-890	93.8	6.2	-
HZ-CuP7	710-820	93	7	-
HZ-CuP	710-793	92.7	7.3	-
HZ-CuP6Sb	690-825	92	6	Antimony: 2.0
HZ-CuPSn	650-700	86.2	6.8	Tin: 7
