MF52 Epoxy Coated High Accuracy 13k Ohm 3950 Temperature Measurement Thermistor Temperature Sensor

Click here to contact

Product details

Wire:	PVC or silicone	Response time:	about 7 seconds
range of working temperature:	-40~+125℃	payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram
Supply capacity:	100000 pieces per day	data sheet:	please contact
Rated resistance:	0.5~5000kΩ	place of origin; place of origin:	Anhui, China
Insulation resistance:	≥100MΩ	Packaging Materials:	Dumax Alloy
B value:	2500~5000K	Manufacturer Part Number:	MF52
port:	Shanghai	Types of:	NTC thermistor
Dissipation factor:	About 2 mW/℃	Packaging Details:	export package
application:	Electronics and Automotive	Packaging/Case:	epoxy coating

Product Description

thing	unit	performance range	Test Conditions
Rated resistance R25℃	Kiloohms	0.5～5000 (±0.5%～±5%)	+25℃±0.05℃ PT≤0.1mw
B value B25/50	Potassium	2500～5000 (±0.5%～±3%)	+25℃±0.05℃, +50℃±0.05℃ PT≤0.1mw
Response time	small	about 6	in liquid
Dissipation factor	mW/℃	about 0.8	in still air
Insulation resistance	megohm	about 100	500VDC
range of working temperature	℃	-50～+300	in still air

- Glass encapsulation, strong structure, good heat resistance, can work in harsh environments.

-Small size and light weight, suitable for automatic plug-in installation and large-scale production.

- Stable work, high reliability and high precision.

Product Usage

-Temperature control and thermal protection circuits for home appliances and industrial equipment.

-Temperature sensing elements for automated office equipment.

-Instrument coils, automotive circuits, integrated circuit modules, transistor amplifier circuits.

- Temperature compensation circuits such as quartz crystal oscillators and thermocouples.

- Suitable for all kinds of NTC temperature sensors.
