JPX 202 100 pairs of cable side terminals high-density MDF main distribution frame protection connection block

Supplier: Cixi Anshi Communication Equipment Co., Ltd.
Region: Zhejiang, China
Contact: Ms Lulu Cen
Price: $27.00 / 1 - 99 sets
$26.00 / 100 - 999 sets
$25.00 / >=1000 sets
Min. Order: 1 set

Click here to contact

Product details

brand:	Ann's	Material:	Plastic and Phosphor Bronze
port:	Shanghai or Ningbo	Supply capacity:	3000 sets per week
Certificate:	CE ROHS ISO9001	payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram
place of origin; place of origin:	Zhejiang, China	model:	main distribution frame
Packaging Details:	pack	capacity:	100 pairs
application:	telecommunications	type:	Horizontal, terminal block
aspect:	Height x Width x Depth = 175x140x152

Product Description

feature:

The protective junction block is used at the entrance of the relay below 2M to the copper wire of the local network or public communication telephone, providing a four-level sound and light alarm system for overvoltage and overcurrent within the range. It can clearly distinguish the visual alarm circuit and prevent external overvoltage and overcurrent signals from causing damage to the telephone exchange. Internal and external wiring for switches and user access wires.

feature

1. The silver and copper on the surface of the reed are made of high-quality elastic materials, and the wire diameter can be 0.4-0.6mm

2. The shell is made of high-quality plastic, with grounding and alarm devices.

Main performance parameters:

working environment:

(1) Working temperature: 0～+40 (degrees) (2) Relative humidity: ≤85% (30 degrees)

(3) Atmospheric pressure: 70~106 (kpa)

Electrical properties:

(1) Insulation resistance ≥ 1000MΩ

(2) High voltage protection>3000V(DC)/mm No breakdown, no arc.

(3) Contact resistance ≤ 7mΩ The connection contact resistance between the reed and the terminal is ≤ 3mΩ

(4) Pull force: ≥25N
