Original new GPON EPON GEPON ONU 2POTS+4FE+USB+WiFi ONT HG8346M

Supplier: Changsha Silun Network Technology Co., Ltd.
Region: Hunan, China
Contact: Ms Sharon Zhang
Price: $6.00 / 1 - 999 pieces
$3.00 / >=1000 pieces
Min. Order: 1 piece

Click here to contact

Product details

color:	white	weight:	0.5kg
Routing function:	Internet, IPTV and VoIP services	strength:	DC 12V
GPON Features:	: Class B+ optical module	Wireless network function:	802.11b/g/n
Packaging Details:	ONU carton packaging Huawei HG8346M GPON /EPON ONU carton packaging	Warranty:	1 year
place of origin; place of origin:	China	type:	ONU
Function:	VLAN support	payment terms:	L/C,Western Union,D/P,D/A,T/T,MoneyGram
port:	any port in China	model:	HG8346M
Voice function:	SIP or H.248 protocol	Supply capacity:	5000 pieces per day

Product Description

describe:

HG8346M is an Optical Network Terminal (ONT), which is a high-end home gateway in the FTTH solution. Utilize GPON technology to provide ultra-broadband access for home and SOHO users. HG8346M provides 2 POTS ports, 4 FE adaptive network ports and 1 Wi-Fi port. The HG8346M features high-performance forwarding to ensure an excellent VoIP, Internet and HD video service experience. Therefore, HG8346M provides a complete terminal solution and future-oriented business support capability for FTTH deployment.

Device parameters
Dimensions (HxWxD)		(176 x 138.5 x 28)mm (without external antenna)
weight		about 500 grams
Operating temperature		0°C to +40°C
Working humidity		5% RH to 95% RH (non-condensing)
power adapter input		100-240 VAC, 50-60 Hz
System power		11-14 VDC, 1A
Static power		6W
Maximum power consumption		14W
port		2POTS+4FE+Wi-Fi+1USB
index		Power/PON/LOS/LAN/TEL/USB/WLAN/WPS
interface parameters
Ethernet port	Ethernet port based VLAN tagging and tag removal • 1:1 VLAN, N:1 VLAN, or VLAN transparency spread • QinQ VLAN • Limit the number of learned MAC addresses • MAC address learning
GPON port	• B+ grade • Receive sensitivity: -27dBm • Wavelength: US 1310nm, DS 1490nm • WBF • Flexible mapping between GEM Port and TCONT • GPON: same as SN or password Authentication as defined in G.984.3 • Bidirectional Forward Error Correction • SR-DBA and NSR-DBA
Wireless LAN	• IEEE 802.11 b/g/n • 2 x 2 MIMO • Antenna gain: 2 dBi • WMM • Multiple SSIDs • WPS
POTS port	• Maximum REN: 4 • G.711A/μ, G.729a/b and G.722 encoding/decoding • T.30/T.38/G.711 fax mode • DTMF • Emergency calls (using SIP protocol)
USB port	• USB2.0 • FTP-based network storage

Packaging and Shipping

Bale:
1. All products are packed in cartons, which can be effectively protected from damage.
2. Packing according to customer requirements

Shipping:
1. We ship small orders via DHL/FedEx/TNT/etc. You can receive your package in about 3-5 days around the world.
2. For large orders, we will arrange air freight for you, so it will be much cheaper than DHL, UPS, etc.
3. You can choose your own shipping agency, we will provide good cooperation.

our service

After-sales service
1. We can provide detailed documentation and remote assistance for equipment installation and configuration.
2. Warranty period: 1 year. (After the warranty period, the corresponding maintenance service fee will be charged.)
3. The company promises to deliver the goods within 7 days or 15 days, and returns and exchanges in full due to quality problems.
