Ungar Auto-Matic press for the production of single-use aluminium foil containers

Product details
port:ShanghaiTotal power:15kW
Packaging Preview:payment terms:letter of credit, wire transfer
place of origin; place of origin:Shanghai, Shanghai, ChinaSupply capacity:30 sets per month
color:greenApplicable industries:manufacturing plant
Warranty:1 yearAfter-sales service provided:engineer
Marketing Type:Hot Products of 2019Health status:new
brand:AngelPackaging Details:wooden box
Voltage:380V-50/60Hz-3 phaseWeight (kg):12000
Delivery Details:60-90 days after down paymentVideo external inspection:if
Mechanical test report:Not availableCavity:2-4 cavity
Showroom location:not any

Fully Automatic Disposable Aluminum Foil Container Press


Product Description


Components of this production line:

1. Automatic document feeder

2. Punch

3. Automatic stacker

4. Automatic waste collector

5. Electrical control system

6. Stamping die


Nominal force 800KN, H type press
journey time 20-70 times/min
Slider stroke (optional size) 240/260mm (optional)
Maximum mold installation height 450mm
Die height adjustment 80mm
Distance from slider center to body 610mm
Adjustable work block size X2 1000(L)x220(W)x300(H)mm x2
Slider Bottom Dimensions 520×520mm
Bottom of Aperture Slider 340 x 460 mm
Centering hole size (diameter × depth) 50 x 90 mm
Press Type Electric closing height adjustment
By net weight 11,000KG
Voltage & Frequency (Optional) 380V, 50/60Hz, three-phase
total power 15kW
Press Dimensions (LxWxH) 2500x1300x3800mm


  • It is welded by steel plate with high strength.
  • The main motor is manufactured by Siemens.
  • Adopt combined pneumatic friction clutch and brake.
  • The cluster gears are lubricated with flood oil.
  • Six-sided rectangular elongated guide rail;
  • Equipped with hydraulic overload protection device.
  • Electric closing height adjustment with digital display.
  • Equipped with lifting balance cylinder.
  • Imported double valve.
  • Electric forced grease lubrication system.
  • The balance cylinder adopts a manual lubrication system.
  • A set of blowing device
