Single-phase 40A 63A 230V rail type adjustable over and under voltage VA protection relay Products from Yueqing Junxiong Imp. & Exp. Co., Ltd.

Product Details

application:	Voltage protection	Supply capacity:	100000 pieces/month
payment terms:	Western Union, wire transfer	model:	VA-63
product name:	40A 63A 230V DIN rail adjustable over and under voltage VA protector	Delay setting:	1-400 seconds
Rated current:	1-63A or 1-40A setting	Overcurrent settings:	1-30 seconds
Overvoltage setting:	230V-300V	Voltage:	230V
Packaging Details:	Single-phase 40A 63A 230V rail type adjustable over and under voltage VA protection relay	Packaging Preview:
port:	Ningbo Shanghai	Rated frequency:	50/60Hz
brand:	Junsai Le	strength:	alternating current
Warranty:	1 year	place of origin; place of origin:	Zhejiang, China
Undervoltage settings:	140V-210V	Package:	100PCS/box

63A 230V DIN Rail Adjustable Over and Under Voltage Protection Device Protection Relay with Over Current Protection
Single-phase 40A 63A 230V rail type adjustable over and under voltage VA protection relay
Function:
1. Under-voltage protection 210V-140V (adjustable) (default: 160V)
2. Overvoltage protection 230V-300V (adjustable) (default: 280V)
3. Overcurrent protection 1A-40A/63A (adjustable) (default: 20A)
4. Reconnection time (delayed connection time): 1s-300s (default: 5s)
5. Voltmeter
6. Ammeter
Rated voltage: 220V; Frequency: 50Hz/60HZ
Overcurrent protection: 1A-40A/63A (adjustable) (default: 20A)
Undervoltage action shutdown value: 210V-145V (adjustable) (default: 160V)
Overvoltage action shutdown value: 230V-300V (adjustable) (default: 280V)
Reconnection time (delayed connection time): 1s-300s (default: 5s)

rated power	AC 220V
Operating voltage range	AV 80-400V
Rated frequency	50/60Hz
Set the amp range	1-63A
Overvoltage range	230-300V
below the voltage range	140-210V
O/U voltage delay	0.5S
reset/status delay	1S-600S
accuracy	1%
Rated insulation voltage	400A
