China Factory 1000W Wind Vertical Turbine Generator Replacement Free Energy Windmill 12V 24V MPPT Controller

Click here to contact

Product details

Cut-in wind speed\|(m/s):	3 m/s	payment terms:	L/C,Western Union,D/P,D/A,T/T,MoneyGram
Control System:	electromagnet	rated power:	400w 600w 1000w 2000w 3000w
Packaging Preview:		model:	JLC4-600
Warranty:	3 months - 1 year	custom made:	Yes
place of origin; place of origin:	Jiangsu, China	Start Wind Speed\|(m/s):	2m/s
The output voltage:	12V/24V	Safe wind speed (m/s):	≤40m/s
Rated wind speed\|(m/s):	11m/s	Rated Voltage (AC):	12v/24v/48V/96V
brand:	Nine Forces	Number of blades:	2
Blade material:	glass fiber	Certification:	ce
rated power:	400W	dynamo:	Three-phase permanent magnet suspension motor
Rotor diameter:	0.46m	port:	Lianyungang Qingdao
Packaging Details:	1*carton packing 1set including wind turbine, generator, controller	Supply capacity:	1200 sets per month

Product Description

Design/Model	FS-400	FS-600	FS-1000	FS-2000	FS-3000
Start Wind Speed\|(m/s)	1.3m/s	1.3m/s	1.3m/s	1.5m/s	1.5m/s
Cut-in wind speed\|(m/s)	2.5m/s	2.5m/s	2.5m/s	3 m/s	3 m/s
Rated wind speed\|(m/s)	11m/s	11m/s	11m/s	11m/s	11m/s
Rated voltage (AC)	12/24V	12/24V	12/24V/48V	24V/48V/96V	48V/96V
Rated power (W)	400W	600W	1000W	2000W	3000W
Maximum power (W)	450W	650W	1050W	2100W	3100W
Blade rotor diameter (m)	0.52	0.52	0.52	0.67m	0.8m
Product assembly weight weight (kg)	<23kg	<23kg	<25kg	<40kg	<80kg
Blade height (m)	1.05	1.05m	1.3m	1.5m	2m
Safe wind speed (m/s)	≤40m/s
Number of blades	2
Blade material	glass fiber
dynamo	Three-phase permanent magnet suspension motor
Control System	electromagnet
Installation height (m)	7-12m(9m)
Generator protection level	IP54
Working environment humidity	≤90%
high:	≤4500m
Overspeed Protection	Electromagnetic brake
Overload protection	Electromagnetic brakes and unloading units
