Linear guide rail and ball screw set for CNC machine
- 10.00 set
| Delivery Detail: | 5~30days; | Place of Origin: | China (Mainland); |
| Model Number: | SFU1605 HGH20; | Length: | 100~4000 mm; |
| Supply Ability: | 50000 Meter/Meters per Month; | Product name: | Cnc Ball Screw; |
| Port: | Shanghai; | Manufacturing Process: | Rolled Thread; |
| Material: | GCr15; | Payment Terms: | L/C,T/T,Western Union,paypal,escrow; |
| Packaging Detail: | carton or wooden case according to clients requirements; | Brand Name: | NTL; |
Linear guide rail and ball screw set for CNC machine
Contact Us
sales manager
Changsha Terry Machinery Co.,Ltd
Tel:+86-731-85782665
Fax:+86-731-85515405
Skype:danalove329
Email:dana(at)ntl-bearing.com
Part No. | Screw diameter | PH | Ball | n | D
| D3 | D4 | H | B | L | L(D) | D M | D 5 | |
SFU1204-3 | 12 | 4 | 2.381 | 3 | 22 | 42 | 32 | 36 | 8 | 36 | 6 | 4.7 | ||
SFU1605-3 | 16 | 5 | 3.175 | 3 | 28 | 48 | 38 | 40 | 10 | 44 | 85 | 6 | 5.5 | |
SFU2005-3 | 20 | 5 | 3.175 | 3 | 36 | 58 | 47 | 44 | 10 | 44 | 85 | 6 | 6.6 | |
SFU2505-3 | 25 | 5 | 3.175 | 3 | 40 | 62 | 51 | 48 | 10 | 44 | 85 | 6 | 6.6 | |
SFU2005-4 | 20 | 5 | 3.175 | 4 | 36 | 58 | 47 | 44 | 10 | 44 | 6 | 6.6 | ||
SFU2505-4 | 25 | 5 | 3.175 | 4 | 40 | 62 | 51 | 48 | 10 | 50 | 6 | 6.6 | ||
SFU3205-4 | 32 | 5 | 3.175 | 4 | 50 | 80 | 65 | 62 | 12 | 52 | 98 | 6 | 9 | |
SFU4005-4 | 40 | 5 | 3.175 | 4 | 63 | 93 | 78 | 70 | 15 | 55 | 6 | 9 | ||
SFU1610-3 | 15.3 | 10 | 3.175 | 3 | 28 | 48 | 38 | 40 | 10 | 45 | 6 | 5.5 | ||
SFU2010-3 | 20 | 10 | 3.175 | 3 | 36 | 58 | 47 | 44 | 10 | 45 | 6 | 6.6 | ||
SFU2510-3 | 25 | 10 | 4.763 | 3 | 40 | 62 | 51 | 48 | 10 | 71 | 6 | 6.6 | ||
SFU2510-4 | 25 | 10 | 4.763 | 4 | 40 | 62 | 51 | 48 | 10 | 83 | 6 | 6.6 | ||
SFU3210-4 | 32 | 10 | 6.35 | 4 | 50 | 80 | 65 | 62 | 12 | 90 | 6 | 9 | ||
SFU4010-4 | 40 | 10 | 6.35 | 4 | 63 | 93 | 78 | 70 | 14 | 93 | 6 | 9 | ||
SFU5010-4 | 50 | 10 | 6.35 | 4 | 75 | 110 | 93 | 85 | 16 | 95 | 6 | 11 | ||
SFU6310-4 | 60 | 10 | 6.35 | 4 | 90 | 125 | 108 | 95 | 18 | 97 | 6 | 11 | ||
SFU2505-4 | 25 | 5 | 3.175 | 3 | 40 | 62 | 51 | 48 | 10 | 50 | 6 | 5.5 | ||
SFU3205-4 | 32 | 5 | 3.175 | 4 | 50 | 80 | 67 | 62 | 12 | 51 | 6 | 6.6 | ||
SFU2505-3 | 25 | 5 | 3.175 | 3 | 40 | 162 | 51 | 10 | 55 | 6 | 5.5 | |||
SFU5005-4 | 50 | 5 | 3.175 | 4 | 71 | 110 | 90 | 85 | 14 | 55 | 6 | 9 | ||
Ball screw SFU series :
Features:
1.high precision , lower noise
2.all kinds of item
3.delivery in time
4.high speed operation and long durability
5. low clearance
6.cold rolled
Applications
1.engraving machines
2.high speed MachineryCNC Machinery
3.window machines
4.Semi-Conductor Equipment
5.electronic equipment,automation ,medical equipment
