Proton Premium Green Black Heat Shrink Tubing; Heat Shrink Sleeves; Insulating Heat Shrink Tubing

Supplier: Wenzhou Baoteng Electrical Co., Ltd.
Region: Zhejiang, China
Contact: Ms Ada Chen
Price: $3.00 / 1 - 199 pieces
$1.20 / >=200 pieces
Min. Order: 1 piece

Click here to contact

Product details

payment terms:	L/C,Western Union,T/T	Rated voltage:	600V
color:	red yellow green yellow green	feature:	durable
model:	high speed rail	tensile strength:	≥10.4MPa, 10.4Mpa
Shrinkage:	2:1 3:1 4:1	product name:	insulating tube
Packaging Details:	200/roller/100/roller/50/roller	Classification:	usable
application:	low voltage	Function:	insulating sleeve
title:	heat shrink tube	place of origin; place of origin:	Zhejiang, China
usage:	coating	type:	insulating sleeve
brand:	Proton	Material:	physical education

Proton Premium Green Black Heat Shrink Tubing; Heat Shrink Sleeves; Insulating Heat Shrink Tubing

Banner

Product Description

If you need more information about this product. PleaseClick here Tono Contact our salesperson and we will provide you with more information about the product. You can get samples as soon as possible.

other products

main feature:

1) Material: PE

2) Shrinkage ratio: 2:1

3) Rated voltage: 600V

4) Tensile strength: 10.4 Mpa

5) Operating temperature: -30°C to 125°C.

6) Shrinkage temperature: 100°C to 1110°C.

7) Color: black/white/red/blue/green/yellow and other colors are available upon request.

Dimensions (mm)	Actual size (mm)	Wall thickness before shrinkage (mm)	Wall thickness after shrinkage (mm)	Packaging (m/roll)	Weight (kg/roll)
Ø1	1.5±0.2	0.185±0.03	0.37±0.05	200	0.5
Ø2	2.5±0.2	0.19±0.03	0.38±0.05	200	0.7
Ø2.5	3.0±0.2	0.2±0.03	0.40±0.05	200	0.85
Ø3	3.5±0.2	0.2±0.03	0.40±0.05	200	0.9
Ø3.5	4.0±0.3	0.2±0.03	0.40±0.05	200	1.05
Ø4	4.5±0.3	0.21±0.03	0.42±0.05	200	1.2
Ø5	5.5±0.4	0.21±0.03	0.42±0.05	200	1.2
Ø6	6.5±0.4	0.21±0.03	0.42±0.05	200	2
Ø8	8.5±0.5	0.21±0.03	0.42±0.05	100	0.9
Ø10	10.5±0.5	0.24±0.03	0.48±0.05	100	1.1
Ø12	12.5±0.5	0.25±0.03	0.50±0.05	100	1.2
Ø14	14.5±0.5	0.26±0.04	0.52±0.07	100	1.5
Ø16	16.5±0.5	0.29±0.04	0.58±0.07	100	1.9
Ø18	19±0.5	0.29±0.04	0.60±0.07	100	2
Ø20	21±0.5	0.31±0.04	0.62±0.07	100	2.4
Ø22	23±0.5	0.32±0.04	0.65±0.07	100	2.5
Ø25	26±0.5	0.35±0.04	0.70±0.07	25	0.9
Ø30	31.5±0.5	0.39±0.04	0.78±0.07	25	1.06
Ø35	36.5±0.5	0.39±0.05	0.78±0.07	25	1.2
Ø40	41.5±0.5	0.39±0.05	0.78±0.07	25	1.5
Ø50	≥50	0.41±0.05	0.80±0.1	25	1.85
Ø60	≥60	0.42±0.05	0.86±0.1	25	2.15
Ø70	≥70	0.43±0.05	0.88±0.1	25	2.9
Ø80	≥80	0.45±0.05	0.90±0.1	25	3.8
Ø90	≥90	0.50±0.05	1±0.1	25	4.5
Ø100	≥100	0.55±0.05	1±0.1	25	5.2
Ø120	≥120	0.57±0.05	1.2±0.1	25	6
Ø150	≥150	0.60±0.05	1.5±0.1	25	7.55
