Ultrasonic Embroidery Lace Machine (AH-200S)

Product details
strength:2500Wpayment terms:L/C,T/T,Western Union
place of origin; place of origin:Jiangsu, ChinaWarranty:1 year
Voltage:220VMaximum sewing thickness:3 cm
brand:ohengAfter-sales service provided:Video technical support, online support, free spare parts, on-site installation and commissioning training, on-site maintenance and repair services, overseas third-party support is available
After Warranty Service:Video technical support, online support, spare parts, on-site maintenance and repair servicesAuto grade:semi-automatic
Supply capacity:30 sets per dayApplicable industries:Food and Beverage Factory, Retail
port:ShanghaiPackaging Details:Wooden case or as customer's request
Certification:cecolor:silver
Health status:newDimensions (L*W*H):1200X600X1200 mm
Showroom location:not anyweight:110kg
Key words:Ultrasonic Embroidery Lace MachineLocal service location:not any



basic components
1.New PC intelligent ultrasonic generator;
2.20KHz ultrasonic transducer unit;
3.Bottom mold fixed suspension structure;
4.Single motor speed control system;
5.Manual drum lifting system;


feature
1.Built-in PC chip, multi-channel ultrasonic protection system, make the machine run safely;
2.Powerful ultrasonic power, adjustable in three gears (maximum, medium, and minimum) to meet welding requirements of different materials and thicknesses;
3.The machine performance has reached the international level, using automatic frequency tracking system and ultrasonic soft start technology;
4.A variety of idler patterns, other idler designs can be provided according to customer requirements;
5.Four times faster than sewing machines and requires minimal operator training.


Function
1. Trim:Straight or curved edge trimming and edge melting, smooth without burrs;
2. Seal:Two or more layers of fabrics are sewn together, no need to change sewing needles, and the welding strength is good;
3. Punch holes:Cut out holes of various patterns and perform side melting treatment;
4. Slitting:Single or multiple pieces of material are cut at the same time, and burr-free side melting treatment is performed;
5. Forming:At the same time cutting, sealing, embossing, one production.





Applicable materials:



All kinds of artificial leather and fabrics, non-woven fabrics, spunbond cotton, thermoplastic films, chemical plastic sheets. Such as nylon, polyester, ABC, PC, PU, ​​PE, PP, PS, etc.





Technical Specifications

commodity

Ultrasonic sewing machine

Specification

AH-200S

Output (W)

2500W

Frequency (KHz)

18KHz

Voltage (V)

220V

Die size

Width: 0-195mm

Speed ​​of work

0-25m/min

Welding area (mm)

Ø195mm

Dimensions (L×W×H)

1200*600*1200mm

Net weight (kg)

110kg



application:

Ultrasonic lace machine is easy to maintain and repair. is the economy. Can be used to make lace clothing, napkins, tablecloths, non-woven bags (shopping bags), etc.
