High Power Booster Pump Brass Water Flow Switch 1 Inch For Water Control Two Way Solenoid Water Solenoid Valve
- 6.50 10 - 98 pieces
- 6.40 99 - 298 pieces
- 6.20 299 - 499 pieces
- 6.00 >=500 pieces
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| Single package size: | 8X8X6 cm | the color of car: | yellow, black, red, green |
| Liquid temperature: | <100℃ | Certification: | CCC |
| brand: | CXZTCL | model: | CX-800 |
| Liquid pressure: | <0.6Mpa | place of origin; place of origin: | Fujian China |
| Rated voltage: | 220VAC | Applies to: | Water or other liquids with similar physicochemical properties |
| Packaging Details: | 1. One piece per box 2. One box of 50prs, carton size: 33*25*22cm 3. About 24kg per box | Flow rate: | 6-7 L/min, G1/2"-G1/2" |
| Gross weight per piece: | 0.241 kg | media type: | liquid |
| Packaging Preview: | Operating temperature: | <100℃ | |
| connect: | G1/2" 3/4" 1" 1.2" 1.5" 2" | Key words: | Water control flow switch |
| Sales unit: | single product | product name: | Flow switch |
| application: | Monitor liquid flow |
Product Description
1. Stable performance; the induction chamber, the magnetron chamber and the electronic components are designed separately to avoid the switch failure caused by the magnetic adsorption of the iron in the pipeline.
2. The high temperature resistant material enables the product to be used for hot water.
3. Start with low water pressure; The return spring is made of high-quality stainless steel; The water pump can be started when the water pressure is >0.03KG.
4. The electronic component is used as a control device, and it will not produce sparks when working, which is safe.
5. This product is widely used in households in low-pressure areas, especially the low-pressure ignition of water heaters, and the automatic water circulation of solar water heaters.
2. The high temperature resistant material enables the product to be used for hot water.
3. Start with low water pressure; The return spring is made of high-quality stainless steel; The water pump can be started when the water pressure is >0.03KG.
4. The electronic component is used as a control device, and it will not produce sparks when working, which is safe.
5. This product is widely used in households in low-pressure areas, especially the low-pressure ignition of water heaters, and the automatic water circulation of solar water heaters.
Model | size | Maximum current | Working current | strength |
CXZ-2010 | G 2"-2" | 5A | 2A | 2200w |
CXZ-802 | G 1.5"-1.5" | 5A | 2A | 2200w |
CXZ-801 | G1.2"-1.2" | 4A | 1.6A | 2200w |
CXZ-800 | G1"-1" | 4A | 1.6A | 800w |
CXZ-300/370 | G1"-3/4" | 5A | 2A | 300-370w |
CXZ-300 | G 3/4"-3/4" | 5A | 2A | 300w |
CXZ-300 | G 3/4"-1/2" | 5A | 2A | 300w |
CXZ-300 | G 1/2"-1/2" | 5A | 2A | 300w |
CXZ-200 | G1"-3/4" | 4A | 1.6A | 200w |
CXZ-200 | G 3/4"-3/4" | 4A | 1.6A | 200w |
CXZ-200 | G 3/4"-1/2" | 4A | 1.6A | 200w |
CXZ-200 | G 1/2"-1/2" | 4A | 1.6A | 200w |
CXZ-120 | G1"-3/4" | 1.5A | 0.5A | 120w |
CXZ-120 | G 3/4"-3/4" | 1.5A | 0.5A | 120w |
CXZ-120 | G 3/4"-1/2" | 1.5A | 0.5A | 120w |
CXZ-120 | G 1/2"-1/2" | 1.5A | 0.5A | 120w |
CXZ-60 | G1"-3/4" | 1A | 0.3A | 90w |
CXZ-60 | G 3/4"-3/4" | 1A | 0.3A | 90w |
CXZ-60 | G 3/4"-1/2" | 1A | 0.3A | 90w |
CXZ-60 | G 1/2"-1/2" | 1A | 0.3A | 90w |
detailed picture
