Heavy 6 Inch Gold&Diamond Mining Dredge

The new 6 inch heavy duty dredge is equipment for economy and portability. It can be quickly and easily broken down into small components where two men can transport the dredge manually.

It has large walkways on the decks that can accommodate several divers and provide ease of access around all working parts of the dredge.

The larger 23 hp engines offer greater suction depths up to 18 meter. The sluice box sets at the surface of the water to reduce the water lift and increase suction power, which are equipped with a winch leveling system for precise tilt and sluice box adjustment. The sluice box is equip rubber mat inside which designed to recover fine gold and gemstones.

All dredges are equipped with a compressor for an ample air supply for two divers.

The suction system is equipped with an oversized power jet and twin eductor systems to reduce the occurrence of rock jams.

Mounted on modular crosslink flotation modules measuring 8 pieces high impact plastic polymer pontoons, After assembly flotation dimension is approximately 2.5m wide and up to 4.65m in length.

Sluice box dimension is 0.56m wide and up to 3.6m in length. All frames have been reinforced for a more stable working platform.
Size Model Pump/Power Air Compressor Max Dredging Depth Capacity Fuel Consumption Suction Hose Length N.W/G.W
6 inch 6211M DW180/GX200*2sets T-80 8m 12cbm/h 3.4 l/h 6" * 7m 200kg/250kg
6 inch 6246V JL350/23HP K263 18m 14cbm/h 4 l/h 6" * 10m 550kg/650kg
Note:
The machine with air compressor contains: Air bag x 1 pc, T80 x 1 pc, diving air pipe x10m, Diving respirator x 1 pc. Diving mask, diving suit, lead, protective gloves, diving boots and other personal equipment can be purchased according to somatotype and water temperature.
