Hot Slitting Machine with rotary Die-cutter for blank label
- 8000.00 set
| Automatic Grade: | Automatic; | Marketing Type: | Hot Product 2020; |
| Supply Ability: | 60 Sets per Month; | Place of Origin: | China; |
| Weight: | 850KG; | After Warranty Service: | Video technical support,Online support; |
| Payment Terms: | L/C,T/T; | Video outgoing-inspection: | Provided; |
| Brand Name: | WEIGANG; | Machinery Test Report: | Provided; |
| Warranty of core components: | 1 Year; | Packaging Detail: | packed with wooden case; |
| Key Selling Points: | Automatic; | Showroom Location: | None; |
| Dimension(L*W*H): | 1600X900X1300mm; | Voltage: | 220V; |
| Type: | die cutting machine; | Port: | shanghai; |
| Applicable Industries: | Label; | Local Service Location: | None; |
| Warranty: | 1 Year; | Core Components: | Engine,Bearing,Motor,Gear; |
| Certification: | CE ISO TUV; | After-sales Service Provided: | Online support,Field installation, commissioning and training; |
| Condition: | New; |
A. DESCRIPTION:
1) DK-320G slitting machine with rotary die-cutting fuction is a new product, it equipped with high accurate rotary die-cutting system.
2) This machine is suitable for blank adhesive labels. Die-cutting, lamination (option), slitting can be finished in one process.
3) It has the function of automatic meter and label counting, automatic stopping, web guiding by photoelectric eye.
4) The machine has the characteristics of compact structure, fast speed, high efficiency, easy operation, accurate slitting, steady running etc.
B. MAIN TECHNICAL SPECIFICATIONS:
|
Model |
DK-320G |
|
Slitting speed |
100m/min |
|
Die cutting speed |
100m/min |
|
Die-cutting repeat length |
190.5-508mm |
|
Max web width |
320mm |
|
Max unwinding diameter |
500mm |
|
Max. rewinding diameter |
480mm |
|
Power supply |
220V±10% ,1.5KWS |
|
Overall dimension |
1600X900X1300mm |
|
Machine weight |
About 850kgs |
1. Q: Are you factory or trading company?
A: We are a factory in this field nearly 20 years (Formally named Ruian Donghai Printing
Machinery Co.,Ltd.).
2. Q:How does your factory do regarding quality control?
A:Quality is priority. We always attach great importance to quality controlling
from the beginning.
3. Q: why choose Weigang Machinery?
A: We are one of leader in this field(in China). Our quality products and service have enabled us to expand our market from china to more than 60 countries.
Welcome to visit us and contact us freely
Sales: Sky
Phone :0086-13868538672
we-chat:0086-15990776683
