SINOTRUK HOWO 8x4 50 tons Capacity Road Recovery Wrecker Towing Truck for sale

Product details
Fuel Type:Diesel;Dimensions (L x W x H) (mm):11210x2496x3820mm;
Max.Driving Speed:90km/h;Port:China main port;
Packaging Detail:nude packing or according to the customers;Max.lifting weight:50000kg;
Transmission Type:Manual;Supply Ability:300 Set/Sets per Month wrecker towing truck;
Wheel base:1800+4600+1350mm;Brand Name:SINOTRUK HOWO;
Engine model:WD615.96,375hp;Place of Origin:Shandong China;
Emission Standard:Euro 2;Payment Terms:L/C,T/T,Western Union,MoneyGram;
Condition:New;

SINOTRUK HOWO 8x4 50 tons Capacity Road Recovery Wrecker Towing Truck for sale

1.SINOTRUK HOWO 8x4 tow truck wrecker
2.Vehicle Model: ST5381TQZCZ
3.GVW(kg):20750,EURO II Emission standard

4.High quality and competitive price

5.Best after-sales

Product Description

Chassis Model

ZZ1317N4667C

Wheel type

8x4

Driving type

Left hand driving

Engine Model

WD615.96

Engine Power(kw/HP)

276

Outline Dimension(L×W×H) mm

11210×2496×3820

Wheel Base( mm)

1800+4600+1350

Track(front/rear)(mm)

2022/1830

No. of Tire

12

Tire Specification

12.00-20

Approach Angle/Departure Angle

16°/16°

Front Overhang/Rear Overhang (mm)

1500/1960

Free loading

Reorganize and outfit quality Kg

27870

Boom

Max. lifting mass (Kg)

50000

Extension Stroke (mm)

6000

Max. Lifting Height (mm)

12500

Max. Inclination Angle

60°

Rotating Angle

360°

Range of Inclination Angle

0~60°

Underlift

Original Lifting Mass (Kg)

25000

Rating Lifting Mass (Kg)

12500

Rating Lifting Mass Fully Extended (Kg)

7800

Max. Effective Length (mm)

3390

Extension Stroke (mm)

1850

Range of Inclination Angle

-9°~93°

Folding Angle

102°

Outriggers

Longitudinal Span between Front Outrigger and Rear Outrigger (mm)

7765

Transverse Span of Front Outriggers (mm)

6300

Transverse Span of Rear Outriggers

4320

Rating Towing Mass (Kg)

55000

Rating Pulling Power of Winch (KN)

2×250

Length of Cable Wire (m)

50



2. Specification of Lifting



Range(m)

Towing Mass(Kg)

3.5

12500



4

11775



4.5

10234



5

8750



5.35

7800



Attention:

1.Range means the distance between the point of lifting and the center of rear axis

2. Lifting mass means the mass on the lifting point

3. The specifications are measured with outriggers retracted.

Packaging & Shipping

Usually Our Truck can be shipped by Ro-ro ship or Bulk ship or Container or Flat rack.

Packing Detail: Ro-Ro or Bulk base on the ship and port in your country. If the truck on the deck,we will spray antirust paint with free. Usually we will put the truck in cabin of the ship.

Delivery Details: 15-35 days after receiving 30% deposit

Shiping Pictures:



Company Information

About Chinatruck.cc



Our Services

We can supply kinds of service to customers according to customers' request:

1,We Will Check Again Before Sending.



2,Spare Parts Supply:

We have our own spear parts departments,have strong production and distribution capability. We can satisfy your demand within 2-7 days. We always do our best to solve the problems, and put our customers' interests in the first place. And We can Supply Spare Parts For Many Brands, Such as SINOTRUK, BEIBEN, FAW, FOTON, IVECO, SHACMAN, SHANTUI, CIMC, DONGFENG and so on.

To see more, kindly click our spare parts website:

FAQ

FAQ

Q:I want to transport the truck by container, is it ok?

A: Yes, it is ok .But we need take apart the truck.You should reinstall in your country.


Q:How about your product quality?

A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.


Q:I want to be your agent in my country , is that ok?

A: It’s ok, If your quantity is big, we will consider. For the first time 50 units is ok.



Q:I want the front two tyres are bias tyre and the rear 9 tyres are radial tyres, is it ok?

A: We can make the tyres as your requirement to suit your country's need.
