| Capacity: | 500kg; | Applicable Industries: | Home Use,Printing Shops; |
| MOQ: | 1; | Product Name: | L type AGV; |
| Running speed: | 0-40m/min; | Supply Ability: | 600 Piece/Pieces per Month; |
| Warranty: | 1 Year; | Brand Name: | Uwant; |
| Payment Terms: | T/T,Western Union,MoneyGram,Paypal; | After-sales Service Provided: | Field installation, commissioning and training; |
| Packaging Detail: | polyfoam per unit, wooden box for out package; | Moving Direction: | Two-way; |
| Guidance Type: | Magnetic Tape; | Brand: | Uwant; |
| Application: | Industrial Filed; | Place of Origin: | Guangdong China; |
| Port: | yantian, shekou,shenzhen; |
agv slam/logistic robot/agv robot
Its main features are:
1. The size is customized according to the requirements, with other required functions;
2. Exquisite drive module design, no skidding, light and comfortable operation, strong turning;
3. Submersible type, bearing type, traction type, etc., with automatic positioning, central belt can be automatically telescopic bar, large pull, can be customized;
4. In situ rotation technology, turn and turn in situ, which is very suitable for most passageways and other occasions with limited space;
5. The car body is equipped with operation keys, which are easy to operate (press and go, and stop at the station automatically) without professional training;
6. The running speed can be up to 1m/s (the speed can be adjusted at will), which can meet the needs of most workshop logistics;
7. Multi-level safety protection configuration, remote deceleration -> close stop -> crash stop;
| project | Index/parameter |
| Product series | UA32 LF4 -- SP3 |
| Navigation way | Magnetic navigation |
| The control mode | Integrated controller |
| Drive motor | Brushless motor, 200W/ set |
| Drive way | differential |
| The load way | Latent jack-up |
| Maximum load | 300 kg |
| Running direction | Automatic back and forth operation |
| The highest speed | The 30 m/min |
