Free Flow Conveyor Double Plus Chain
- 7.00 >=100 meters
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| Brand Name: | MW; | Function: | link chain; |
| Packaging Detail: | standard sea worthy package; | Place of Origin: | Zhejiang China; |
| Port: | shanghai ,ningbo; | Type: | Roller Chain; |
| Applicable Industries: | Machinery Repair Shops; | Supply Ability: | 100000 Meter/Meters per Day; |
| Standard or Nonstandard: | Standard; | Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram; |
| model: | BS30-C208A,BS30-C210A,BS30-C212A,BS30-C216A; | Material: | Stainless Steel; |
Free Flow Conveyor Double Plus Chain
Product Description
Free Flow Conveyor Double Plus Chain is widely used on conveyor line and the material can be stainless steel or alloy steel based on your request.
FREE FLOW CONVEYOR CHAIN
| OIC CHAIN | PITCH | ROLLER | PIN | CHAIN PLATE | WEIGHT/M | |||||||
| P | d1 | d8 | b1 | b8 | d2 | L | Lc | h2 | T | t | q | |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | |
| BS25-C208A | 25.4 | 15.88 | 24.6 | 5.7 | 10.3 | 3.96 | 32.6 | 36.5 | 12 | 1.5 | 2 | 0.79 |
| BS25-C210A | 31.75 | 19.05 | 30.6 | 7.1 | 13 | 5.08 | 40.2 | 44.3 | 15 | 2 | 2.4 | 1.36 |
| BS25-C212A | 38.1 | 22.23 | 36.6 | 8.5 | 15.5 | 5.94 | 51.1 | 55.7 | 18 | 3 | 4 | 2.19 |
| BS25-C216A | 50.8 | 28.58 | 49 | 11 | 21.5 | 7.9 | 66.2 | 71.6 | 24 | 4 | 5 | 4.06 |
| BS30-C208A | 25.4 | 11.91 | 24.6 | 6.1 | 12.5 | 3.96 | 35.6 | 39.5 | 9.6 | 1.5 | 2 | 0.83 |
| BS30-C210A | 31.75 | 14.8 | 30.6 | 7.5 | 15 | 5.08 | 43 | 47.1 | 12.2 | 2 | 2.4 | 1.27 |
| BS30-C212A | 38.1 | 18 | 37 | 9.75 | 20 | 5.94 | 58.1 | 62.7 | 15 | 3 | 4 | 2.14 |
| BS30-C216A | 50.8 | 22.23 | 49 | 12 | 25.2 | 7.92 | 71.9 | 77.3 | 18.6 | 4 | 5 | 3.55 |
