valve body

Supplier: Ningbo Huarui Automation Equipment Co., Ltd.
Region: Zhejiang, China
Contact: Mr Sheng Xu
Price: $0.10 / >=50 pieces
Min. Order: 50 pieces

Click here to contact

Product details

Original:	Zhejiang;	Material:	Carbon Steel;
Surface treatment:	hard chrome;	Packing:	Carton;
Supply Ability:	10000 Piece/Pieces per Month;	Color:	White;
Packaging Detail:	2623.522cm carton;	Model Number:	1/4'' VALVE BODY;
Function:	Industrial Usage;	Surface:	Chrome Plating;
Delivery Detail:	Shipped in 15 days after payment;	Place of Origin:	Zhejiang China (Mainland);
Port:	Ningbo or Shanghai;	Brand Name:	HRPC;
Size:	1/4"-2";	Payment Terms:	L/C,T/T,Western Union;
Type:	Full port;	Application:	Oil Indutry;
Name:	high pressure valve ball;

Product Description

Carbon steel valve ball

used in below ball valve:

Model	PN(bar)	DN(mm)	Joint Size
KHB-M16×1.5	500	6	M16×1.5
KHB-M22×1.5	500	8	M22×1.5
KHB-M27×1.5	500	10	M27×1.5
KHB-M30×1.5	400	16	M30×1.5
KHB-M36×2	315	20	M36×2
KHB-M42×2	315	25	M42×2
KHB-M52×2	315	32	M52×2
KHB-M60×2	315	40	M60×2

Model	PN(bar)	DN(mm)	Joint Size
KHB-NPT1/8	500	4	NPT1/8"
KHB-NPT1/4	500	6	NPT1/4"
KHB-NPT3/8	500	10	NPT3/8"
KHB-NPT1/2	500	13	NPT1/2"
KHB-NPT1/2	400	16	NPT1/2"
KHB-NPT3/4	315	20	NPT3/4"
KHB-NPT1	315	25	NPT1"
KHB-NPT1¹/4	315	32	NPT1¹/4"
KHB-NPT1¹/2	315	40	NPT1¹/2"
KHB-NPT2	315	50	NPT2"

Model	PN(bar)	DN(mm)	Joint Size
KHB-G1/8	500	4	BSP1/8"
KHB-G1/4	500	6	BSP1/4"
KHB-G3/8	500	10	BSP3/8"
KHB-G1/2	500	13	BSP1/2"
KHB-G1/2	400	16	BSP1/2"
KHB-G3/4	315	20	BSP3/4"
KHB-G1	315	25	BSP1"
KHB-G1¹/4	315	32	BSP1¹/4"
KHB-G1¹/2	315	40	BSP1¹/2"
KHB-G2	315	50	BSP2"

Material sheet:

Specifications:

1. Series Code: KHB3K(BK3) Series Two-Position Three-Way Ball Valve

2. Joint Code: G**, **LR, **SR, PT**, NPT**

3. Valve Body Material: 1-Steel

4. Ball Body Material: 1-Steel, 2-Brass

5. Operating Temperature: 1. -25~+100°C, 2. -30~+170°C

6. Other Airproof: 2-NBR, 4-FPM

7. Handle Type: 02-Aluminium Crooked Handle, 04-Casting Zinc Crooked Handle, 06-Steel Crooked Handle, 09-Without Handle

8. Design Number: To Be Decided By The Manufacturer

9. Surface Disposal: Blank-Phosphoric Polish, G-Electroplated Yellow Zinc

More products for your to choose:

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 3-5 days if the goods are in stock. or it is 20-30 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=5000USD, 100% in advance. Payment>=5000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
