mobile credit card reader, bluetooth smart card reader, wireless card skimmer for android and iOS phone

Supplier: Shenzhen ZCS Technology Co., Ltd.
Region: Guangdong, China
Contact: Mr Gary Chen
Price: $5.00 /piece
Min. Order: 1 piece

Click here to contact

Product details

Application:	sdk and demo app;	Interface:	USB;
Type:	SD Card,XD Card,MMC Card,Memory Stick Card,SM Card,CF Card;	Material:	ABS Plastic;
Rated voltage:	3.3V DC;	Battery capacity:	120mAh;
Support cards:	ISO7811 , ISO7816;	Place of Origin:	Guangdong China;
Encryption method:	3DES, DUKPT;	Brand Name:	ZCS;
Support standard:	EMV4.3, PBOC3.0;	Model Number:	iMxiPay-BL;
Supply Ability:	200000 Piece/Pieces per Month;	Interface:	Bluetooth;
Payment Terms:	L/C,T/T,Western Union,MoneyGram;	Certification:	EMV L1 & L2;
Port:	Shenzhen;	Packaging Detail:	could be customized;
Product name:	Mobile card reader;

mobile credit card reader, bluetooth smart card reader, wireless card skimmer for android and iOS phone

MSR & IC chip card reader

Bluetooth interface with perfect perfomance in compatibility

3DES, DUKPT encryption management

EMV L1&L2 Certified

Free SDK and Demo app

1.0 Introduction
iMixPay-BL is a combination magnetic and IC card reader. It is via Bluetooth connection with a mobile communication device,with a simple mobile payment system that allows mobile devices to read a variety of magnetic stripe cards and contact IC card,such as credit cards, debit cards,signature gift cards, membership cards,driving license, ID card badge etc., can be quickly and securely complete the payment.

2.0 Product Features

Multiple protection: 3DESkey management
LED lights: Light after startup flashing, normally on after connecting the bluetooth.Charging status display red,green charging full display.
Safe and simple: Security algorithms, hardware encryption,client and hardware perfect match just pay a brush.Support online upgrade.

Interbank real-time: Real-time debit transactions,a variety of business real-time arrival.
Concise fashion: Professional design,compact, stylish.
OEM customization: Function, the SDK,look,color and LOGO etc,can be customized
Support Standard: EMV4.3, PBOC 3.0 standard
Card Type: Magnetic cards, Contact IC card

3.0 Technical Data

Interface	Bluetooth
Optional accessories	Dual mode:Support BLE protocol , SPP protocol, support IOS, Android 2.3 above systems
Optional accessories	Single-mode:Support BLE protocol, support for IOS, Android 4.3 system
Color	Blue (color, logo can be customized)
Material	ABS plastic
Weight	30g
Size	60mm(L)15.7mm(W)41.8mm(H)
Operating temperature	0 ℃ ~ 55 ℃ (32 ℉ ~ 131 ℉)
Battery Capacity	120mAh
Rated voltage	3.3V DC
Peak Current	70mA
Operating Current	25mA
Standby Current	10mA
Standby time	10h
Magnetic card
tracks	1/2/3 track selectable
Head life	About 1 million times
Card speed	3 to 60 inches / sec
Card Compatibility	ISO 7811
IC card
Card Compatibility	ISO7816- (1-4) (T = 1, T = 0)
