220V 1.5kva offline ups uninterrupted power supply

Model

PCH1500

Rated Capacity

900W

Input Voltage

145~275Vac

Input Frequency

50Hz±5%

Output Voltage(battery pattern)

220±10%Vac

Output Frequency

82Hz±2%

Output Wave

Square Wave

Transfer Time

6-8ms

Reserve time(full/half load)

5 Minutes/

Nominal Outside Battery DC Voltage name

12V/9AHX2pcs

Battery Type

Valve control free maintenance lead-acid battery

Over-load Ability

Switch off when overload within 110~130%

after 10 seconds and maintain 300ms above 130%

Peak Ratio For Load

3:1(max)

Distortion Rate(full load)Linear Load

<3%

Distortion Rate(full load)non-linear Load

<6%

Communication Software

POWER 2000

Work Temperature

0°C~40°C

Relative Humidity

20~90% Non-condensing

Size mm(WxDxH)

345x120x190 ,

N.W(kg)

9.4

Q 1.what's the payment terms?
A. We accept LC, T/T, PayPal, Western Union, Smallamount payment, Money Gram.

Q 2.Can we have a sample order for voltage regulator?
A.Yes.We welcome to have sample to test and check quality.

Q 3. how's the delivery time ?
A. Sample need 3-10days, big order usual need 20 days more than one container.

Q 4. How to ship the goods? and how long can arrived?
A. There are Express comapny of DHl,UPS, FedEX, TNT for sample shipping. It need 3-5days to arrived. Airline and sea shipping also can be optional.

Q 5.Could you offer Form A or C/O ?
A. It totally not a problem. We can prepare relative documents to forgin affairs office or other
office to apply for this certificate.

Q 6.Would you accept to use our logo ?
A. Yes. If you have good quantity,it absolute no problem to do OEM.

Q 7. How long guarantee period do the products have?
A. There are 24months for our products.

Q 8. what kind of certificate you have ?
A. Our company already Obtained ISO900,CE,EAC,SONCAP,ROHS design and technical patents certificates.

Q9.What's the backup time?How can i decide which model is suitable to my device?
A:Different capacity will have different backup time,with following information,we can choose the most suitable ups to you :
1.What's the device you plan to use?
2.What's the working voltage and current?
3.What's your expected backup time?
If the ups was not used for long time, it is suggested to charge it once every 3~5months
