188Psi External sensor 6-8-10-12-14-16-18-26 wheels Tire Pressure Monitoring system solar power Trailer bus truck TPMS

Click here to contact

Product details

Work temperature:	-40℃ ~ +85℃;	Voltage:	DC12V-24V;
Keyword:	10 wheels truck TPMS;	Model Number:	H2;
Function:	Monitoring Tire Pressure and tire temperature;	Package Preview:	https://sc02.alicdn.com/kf/UTB8ehG7iT_IXKJkSalUq6yBzVXaI.jpg_640x640.jpg,https://sc02.alicdn.com/kf/UTB8wlboB5aMiuJk43PTq6ySmXXaI.jpg_640x640.jpg;
Type:	Digital;	Selling Units:	Single item;
Package Type:	Aluminum color box;	Display:	super big LCD Display;
Sensitivity:	-115dbm;	Product name:	Tire Pressure Monitoring System (TPMS);
Color:	Black;	Single package size:	35X24X13 cm;
Pressure range:	0-13.0Bar/0-188Psi;	Certification:	CE;
Single gross weight:	3 KG;	Type:	digital;
Warranty:	12 Months;	Brand Name:	SPY;
Place of Origin:	Guangdong China;	Usage:	truck Bus trailer;

Product Description

Voltage	12V	Voltage	DC 12V
Color	Black	Work trmperature	-20℃ ~ +75℃
Pressure range	0~13Bar/0~188Psi	Certification	CE
Display	Super big LCD screen	Warranty	12 months
Battery	CR1632-3V Lithium	Function	Monitory tire pressure and tire temperature
Type	Digital	MOQ	100 sets
Model Number	TPMS-H2	Work frequence	433.92MHz
Sensitivity	-115dbm	Port	Zhongshan/Xiaolan

1. Display can ba charged by solat or mini USB charging slot.

2. DIY installation, no need connect cable/cigarette lighter.

3. High-definition colorful LCD display shows pressure&temperature of all tire in circular scrolling motion.

4. Alert immediately when temperature or pressure of tire under abnormal condition. Large capacity battery display.

5. Innovative technology, super long standby time, super long working life, visual and sudible warning, aleeping mode available.

6. Pressure range: 0!

Detailed Images

Minitor Parameter

Sensor Parameter

Working battery	Military lithium battery
Sensor chip	German Infineon
Working humidity	0~100%
Work temperature range	-40℃~100℃
Pressure measurement range	0~13Bar
Transmitting frequency	433.92MHz
Transmitting power	≤5dBm
Temperature display precision	±1℃
Pressure display precision	±0.1Bar
Battery lifespan	5 years
