High-quality three-roll PVC calender/hard and soft PVC sheet production line

Supplier: Qingdao Chaoguangyue Industry Co., Ltd.
Region: Shandong, China
Contact: Mr Daguang Qiu
Price: $6000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Number of rollers:	three	After Warranty Service:	On-site maintenance and repair services
Health status:	new	brand:	cgy
Packaging Details:	Export packing, FCL or as your request.	Weight (kg):	21000 kg
Processing type:	extruder	Core Components Warranty:	5+ years
Certification:	ISO/CE/SGS	Mechanical test report:	if
port:	Qingdao Port or any port in China	Surface heat treatment:	polished; chrome
payment terms:	L/C,Western Union,D/P,D/A,T/T,MoneyGram	place of origin; place of origin:	Shandong China
Power (kW):	75	type:	Rubber Calender
Warranty:	5+ years	Applicable industries:	manufacturing plant
Voltage:	220v, 240v, 380v, 400v, 415v, 440v	Showroom location:	Ukraine, Japan, Malaysia, Turkey, United Kingdom, Vietnam, Brazil, Saudi Arabia, Mexico, Russia
Supply capacity:	30 sets per month	Main selling point:	high productivity
Core components:	PLC, engine, bearing, gearbox, motor, gear, pump	Dimensions (LWH):	732022002900mm
Video external inspection:	if	After-sales service provided:	Engineers can repair machinery overseas
Marketing Type:	normal product

High-quality three-roll PVC calender/hard and soft PVC sheet production line

1. Application

For rubber or plastic calendering, fabric fractionation and rubber or plastic compounding.

2. Features

1. The roller is made of chilled alloy cast iron with a cavity, which can be heated by steam or evenly cooled by water to meet different requirements.

2. The ground working surface is smooth, hard and wear-resistant.

3. The curvature of the upper roller is compensated for the curvature of the roller, so that the thickness of the product is uniform along the width direction.

4. The connecting gear is integrated with the planetary gear reducer.

5. The friction ratio of the rolls can be easily changed by simply turning the friction ratio adjuster to meet the different requirements of topping, slitting and calendering sheets.

6. The whole machine has compact design, low noise and long service life.

7. The roller and the output shaft of the gear box are connected by a gear coupling, and the roller runs smoothly, which is beneficial to the product quality.

8. The machine is driven by a DC motor with thyristor, and the working line speed can be adjusted steplessly within the specified range, which is suitable for various purposes.

9. Equipped with an emergency stop device, which can stop the machine in an emergency. Provide accessories such as let-off device and rewinding device.

3. Technical parameters

Model and parameters	XY3I 630 XY3L 631	XY3I 630 XY3L 631	XY3I 1400	XY3I 1500	XY3I 1730	XY3I 2130
Roll diameter (mm)	230	360	400	450	610	710
Roll working length (mm)	630	1120	1400	1500	1730	2130
Rolling Quantitative	1:1:1	1:1:1	1:1:1	1:1:1	1:1:1	1:1:1
		1:1.38:1.38	0.73:1:1	1:1.38:1.38
	1:1.42	1:1.38:1		1:1.38:1	1:1.5:1
Line speed of middle roller (r/min)	0.8-8	3-21.06	3-26.39	2.62-26.2	5.5-54	8-50
Adjust the nip range (mm)	0-7	0-10	0-10	0-6	0-20	0-20
minute. Calendered product(mm)	0.2	0.2	0.2	0.2	0.15	0.15
Thickness(mm)	0.2	0.2	0.2	0.2	0.15	0.15
Motor power (kw)	100-500	500-	1200	1400	1400	1400
Dimensions (mm)	3168	5550	6500	7420	7010	7650
	890	1640	1500	2200	3950	4560
	1830	2120	2440	2900	3730	4080
About weight (t)	2.6	11	twenty two	26	52	60

Our packing way: export standard (wood packing) or according to your requirements.

our service:

1. We will design, manufacture, install and test the machine according to customer's requirements. Provide relevant personnel training to customers to ensure that customers are fullyMaster the use and maintenance of technology.

2. Our service department listens to customers' feedback at any time and provides backupParts on time.

Welcome to visit our factory, we can show you the working state of the machine:

If our products win your interest, please send us an inquiry and we will provide you with details. We can also manufacture machines according to your requirements.
